DIN 912 A2-70 Stainless Steel Bolt M14 Hexagon Head Driver Type With RoHS Approval
DIN 912 A2-70 Stainless Steel Bolt M14 Hexagon Head Driver Type With RoHS Approval
DIN 912 A2-70 Stainless Steel Bolt M14 Hexagon Head Driver Type With RoHS Approval
DIN 912 A2-70 Stainless Steel Bolt M14 Hexagon Head Driver Type With RoHS Approval
DIN 912 A2-70 Stainless Steel Bolt M14 Hexagon Head Driver Type With RoHS Approval
DIN 912 A2-70 Stainless Steel Bolt M14 Hexagon Head Driver Type With RoHS Approval
Specifications
Brand Name :
BEDE
Model Number :
A2-70
Certification :
RoHS
Place of Origin :
China
MOQ :
1 carton
Price :
USD 0.34 ~ 0.82 per pieces
Payment Terms :
Western Union, T/T, Paypal
Supply Ability :
500000 pieces per week
Delivery Time :
2 days for retail, 5~15 days for wholesale
Packaging Details :
Paper Cartons
Products Name :
SS Bolts
Materials :
Stainless steel SUS304
Driver type :
Hexagon Head
Thread typy :
Partly threaded
Tensile Strength :
700MPa
Size :
M14
Length :
50~150 mm
OED/ODM :
welcome
Description

DIN 912 A2-70 Stainless Steel Bolt M14 Partly Threaded Hex Head Bolts Length 50~150mm SUS304

Description

  • Products Name: Stainless Steel bolt
  • Driver Type: Hexagon Head
  • Thread Type: Partly threaded
  • materials: SUS 304 / 316
  • Tensile Strength: SUS 304 >700 MPa , SUS 316 >800 MPa
  • Executive standard: DIN931 / ISO4014
  • Size: M 14
  • Length: 50~150mm

Specification of Hex head bolt partly threaded.pdf
Date details
DIN 912 A2-70 Stainless Steel Bolt M14 Hexagon Head Driver Type With RoHS Approval

d

b min.
( L ≤ 125mm)

b min.
( L ＞ 125 mm)

 S / mm K min. / mm e / mm L / mm
M22 2d + 6 2d + 12 21 8.62 24.49 50~150


Length and price

  • The following table is infomations of M14 Partly Threaded Hex Head Bolts.
  • For other sizes, please visit our website or contact us via whatsapp +8615915396878
  • For the price of SUS 316 stainless steel materials, It is 1.4 times of this price, the packaging specifications are the same.
  • For the customized size, pls let us know the key data as show in the Date details
  • We also have the high-strength bolts of carbon steel materials, 8.8 ~ 12.9 grade, welcome to contact us if you are interest

Length / mm 50 55 60 65 70 75 80 85
Qty. per carton 330 330 330 300 300 300 270 270
Unit weight / Gram 80.6 86.4 92.2 98 104 110 115 121
Unit piece / USD 0.68 0.72 0.76 0.81 0.86 0.92 0.97 1.00
Carton Price / USD 224.4 237.6 250.8 243 258 276 261.9 270

Length / mm 90 95 100 110 120 130 140 150
Qty. per carton 270 270 240 240 240 240 210 210
Unit weight / KGS 127 133 139 150 162 173 185 196
Unit piece / USD 1.06 1.11 1.16 1.26 1.37 1.45 1.54 1.64
Carton Price / USD 286.2 266.4 278.4 302.4 328.8 348 323.4 244.4

DIN 912 A2-70 Stainless Steel Bolt M14 Hexagon Head Driver Type With RoHS Approval

How to buy

  • The MOQ for each length is 1 Carton,
  • 2~10 cartons, 10% off
  • 10 carton and more, 20% off
  • 100 cartons and more , 30% off
  • 500 cartons and more , 40% off
  • 1000 cartons and more , 50% off

How to pay
About the payment, T/T, Paypal, and Western Union are available, other methods please contact us for negotiation.

T/T Paypal Western Union
Bank Name DBS Bank(Hong Kong) Limited alicechu@szbede.com First name: CAIXIA
Bank Address 11th Floor, The centre, 99 Queen's Road Central,Central,HongKong Last name: CHU
SWIFT Code DHBKHKHH Address: Xinqiao Street,Bao'an District, Shenzhen, China
Account Name XT Shenzhen Bede mold CO, Ltd
account NO. 79969019953
