HVAC And Freezer NTC Temperature Sensor With Plastic Shell Coated Head
HVAC And Freezer NTC Temperature Sensor With Plastic Shell Coated Head
HVAC And Freezer NTC Temperature Sensor With Plastic Shell Coated Head
HVAC And Freezer NTC Temperature Sensor With Plastic Shell Coated Head
HVAC And Freezer NTC Temperature Sensor With Plastic Shell Coated Head
HVAC And Freezer NTC Temperature Sensor With Plastic Shell Coated Head
HVAC And Freezer NTC Temperature Sensor With Plastic Shell Coated Head
HVAC And Freezer NTC Temperature Sensor With Plastic Shell Coated Head
Specifications
Brand Name :
Hefei Minsing
Model Number :
MFT-2
Certification :
REACH ,ROHS
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
6 Million Pieces Per Year
Delivery Time :
7-10 work days
Packaging Details :
Bulk
Head Material :
ABS, Nylon...Tube
Lead Wire :
PVC , XLPE, ...
Head Size :
Customized To Your Demands
Wire Length :
Customized To Your Demands
R25℃ :
0.5KΩ-2000KΩ
B Value :
3000K-4500K
R Tolerance :
1%,2%,3%,5%,10%
B Tolerance :
1%, 2%,3%,5%
Description

Plastic Shell-coated Temperature Sensor, Suitable for HVAC and Freezer

Product Feature:

Wide operating temperature range/ High stability and reliability

Nice looking / Extensive application/ Good protection

Application:

Air-Conditioner / Oven / Refrigerator / Freezer

Specification Explain:

SJ MF T -2 -3950 -502 F

① ② ③ ④ ⑤ ⑥ ⑦

① Minsing Co.,Ltd

② NTC thermistor

③ Encapsulation probe

T: Cylinder tube encapsulated

④ Cylinder tube types: 1 Metal type, 2 Plastic type , 3 Over molded type

⑤ B value(B 25/50℃) Example: 3950:B 25/50℃: 3950

⑥ Standard resistance value at 25℃(R25℃):

Example:502:R25℃ 5KΩ

⑦ R25℃ interchangeability precision:

F(±1%); G(±2%); H(±3%); J(±5%); K(±10%)

HVAC And Freezer NTC Temperature Sensor With Plastic Shell Coated Head HVAC And Freezer NTC Temperature Sensor With Plastic Shell Coated HeadSpecification:

Specification R25℃ (KΩ) B25/50℃ (K) Disspation constant Thermal time constant Operating temp. range
SJMF□-□280-301□ 0.3 2800

ln still air 2.1~15mW/℃

ln still air 25~65s

-40～+150℃
SJMF□-□338/350-202□ 2 3380/3500
SJMF□-□327/338-502□ 5 3270/3380
SJMF□-□327/338-103□ 10 3270/3380
SJMF□-□347/395-103□ 10 3470/3950
SJMF□-□395-203□ 20 3950
SJMF□-□395/399-473□ 47 3950/3990
SJMF□-□395/399-503□ 50 3950/3990
SJMF□-□395/399-104□ 100 3950/3990
SJMF□-□420/425-204□ 200 4200/4250
SJMF□-□440-474□ 470 4400
SJMF□-□445/453-145□ 1400 4450/4530

The sizes above are for reference only. Different encapsulation and electrical parameter can be custom made as requirement.

More detailed data for reference,please visit our website: www.Minsing.com.cn
