DIN 1630 St52.4 Large Diameter Carbon Steel Pipe Circular Shape For Mechanical
DIN 1630 St52.4 Large Diameter Carbon Steel Pipe Circular Shape For Mechanical
DIN 1630 St52.4 Large Diameter Carbon Steel Pipe Circular Shape For Mechanical
DIN 1630 St52.4 Large Diameter Carbon Steel Pipe Circular Shape For Mechanical
DIN 1630 St52.4 Large Diameter Carbon Steel Pipe Circular Shape For Mechanical
DIN 1630 St52.4 Large Diameter Carbon Steel Pipe Circular Shape For Mechanical
Specifications
Brand Name :
New Era
Model Number :
DIN1630
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 tons
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
3000 tons/month
Delivery Time :
45 days
Packaging Details :
Bundles Package, Wooden Box Package
Product Name :
Circular Steel Tube
Delivery Condition :
Normalized
OD Size :
6-152mm
WT Size :
1-15mm
Standard :
DIN1630
Application :
Mechanical Engineering Purpose
Steel Material :
St37.4 , St44.4 , St52.4
Description

1. Product Name: DIN1630 St52.4 Material No. 1.0581 Seamless Carbon Circular Steel Tube for Mechanical Purpose

2. Size Range: OD: 6-154mm, WT: 1-15mm, Length: 5.8m/6m, maximal 11.8m

3. Stable Quality with Comeptitive Price

4. High Performance and Longer Working Life Steel Pipe

Application: DIN1630 Steel Tubes are used in the construction of chemical plant, vessels, pipework and for general mechanical engineering purpose.


100% Eddy Current Testing.
100% Size Tolerance Checking.
100% Tube surface checking to avoid surface defects.

Product Name DIN1630 Seamless Carbon Circular Steel Tube
Material St37.4, St44.4, St52.4
Delivery Condition Normalized
Standard DIN 1630 Steel Tube
Application Construction of chemical plant, vessels, pipework and mechanical engineering
Certificate ISO 9001
HS code 7304319000
Delivery Time 45 days
Pakcing Bundles or Woodern Boxes

Steel Grade

C

Max.

Si

Max.

Mn
St37.4 10255 0.17 0.35 ≥0.35
St44.4 10257 0.20 0.35 ≥0.40
St52.4 10581 0.22 0.004 ≤1.60

Steel Grade

Yield Strength ReH (Mpa)

Wall Tickness in mm

 Tensile Strength ReH (Mpa) Elongation (%)
Symbol Number up to 16 over 16 up to 40

over 40

up to 65

 longitudinal Transverse
St37.4 1.0255 235 225 215 350--480 25 23
St44.4 1.0257 275 265 255 420--550 21 19
St52.4 1.0581 355 345 335 500--650 21 19

DIN 1630 St52.4 Large Diameter Carbon Steel Pipe Circular Shape For MechanicalDIN 1630 St52.4 Large Diameter Carbon Steel Pipe Circular Shape For MechanicalDIN 1630 St52.4 Large Diameter Carbon Steel Pipe Circular Shape For Mechanical

FAQ:

1. Can you provide a sample to check the quality?
We can provide free sample with same or similar sizes for you to check tube quality.
You need to in charge of Express costs.

2. How about your production capacity?
3000 tons/Month.

3. What are your terms of payment?
30%TT in advance, Balance to be paid before shipment.

4. Where is your factory?
Jiaxing city, 2 hours away from Shanghai.

5. How can I get the quotation A.S.A.P?
Please send us an inquiry with full details as following,quotation will sent to you A.S.A.P:
1). Tube Standard
2). Steel Grade
3). Tube Size and Size Tolerance
4). Tube length
5). Quantity
6). If any special requirements

6. How about the minimum order quantity?
Normally for one size above 1 ton.

Welcome to contact us! Thanks.
