Galvanized Seamless Cold Rolled Steel Tube EN10305 - 4 E355 +N For Hydraulic Systems
Galvanized Seamless Cold Rolled Steel Tube EN10305 - 4 E355 +N For Hydraulic Systems
Galvanized Seamless Cold Rolled Steel Tube EN10305 - 4 E355 +N For Hydraulic Systems
Galvanized Seamless Cold Rolled Steel Tube EN10305 - 4 E355 +N For Hydraulic Systems
Galvanized Seamless Cold Rolled Steel Tube EN10305 - 4 E355 +N For Hydraulic Systems
Galvanized Seamless Cold Rolled Steel Tube EN10305 - 4 E355 +N For Hydraulic Systems
Specifications
Brand Name :
New Era
Model Number :
EN10305-4
Certification :
ISO9001,TS16949
Place of Origin :
China
MOQ :
1 tons
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
2000 tons/month
Delivery Time :
45 days
Packaging Details :
Bundles Package, Wooden Box Package
Product Name :
Galvanized Steel Pipe
Delivery Condition :
+C, +LC, +SR, +A, +N
OD Size :
6-88mm
WT Size :
1-15mm
Steel Material :
E235 , E255 , E355
Application :
Hydraulic and Pneumatic Power Systems
Surface :
Galvanized
Description

1. Product Name: Galvanized Seamless Cold Rolled Steel Pipe EN10305-4 E355 +N for Hydraulic Systems
2. Size Range: OD: 6-88mm, WT: 1-15mm, Length: 5.8m/6m, maximal 11.8m
3. Stable Quality with Comeptitive Price
4. +N(Normalized) Heat Treatment, Surface is clean and smooth, without oxide scale
5. Good Extending and Bending Ability.
6. Electro Galvanizing

Quality Control:
1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing or Cold Rolling, On line inspection
5. Heat Treatment: +N
6. Straightening/Cutting to specified length/Finished Measuring Inspection
7. Quality Testing in own lab with Tensile Strength, Yield Strength, Elongation, Hardness, Straightness, etc.
8. Packing and Stocking.
100% Eddy Current Testing.
100% Size Tolerance Checking.
100% Tube surface checking to avoid surface defects.

Product Name EN10305-4 Galvanized Seamless Cold Rolled Steel Pipe
Material E235, E255, E355
Delivery Condition +N (Normalized)
Surface Galvanized
Size Range OD: 6-88mm, WT: 1-15mm
Application High precision purpose, auto parts, oil cylinder, etc
Round Billet Bao Steel, Xingcheng Steel, Zhongtian Steel
Keyword Seamless Cold Rolled Steel Tube
Certificate TS16949, ISO 9001
HS code 7304319000
Delivery Time 45 days
Pakcing Bundles or Woodern Boxes

Steel Grade Chemical Composition
Symbol Material Number

C
Max.

Si
Max.

Mn
Max.

P
Max.

S
Max.
E235 1.0308 0.17 0.35 1.20 0.025 0.025
E255 1.0408 0.21 0.35 0.40--1.10 0.025 0.025
E355 1.0580 0.22 0.55 1.60 0.025 0.025

Steel Grade +C +LC +SR
Name No.

Rm
Mpa

A
%

Rm
Mpa

A
%

Rm
Mpa

ReH
Mpa

A
%
E235 1.0308 480 6 420 10 420 350 16
E255 1.0408 580 5 520 8 520 375 12
E355 1.0580 640 4 580 7 580 450 10

Steel Grade +A +N
Name No.

Rm
Mpa

A
%

Rm
Mpa

ReH
Mpa

A
%
E235 1.0308 315 25 340--480 235 25
E255 1.0408 390 21 440--570 255 21
E355 1.0580 450 22 490--630 355 22


Galvanized Seamless Cold Rolled Steel Tube EN10305 - 4 E355 +N For Hydraulic SystemsGalvanized Seamless Cold Rolled Steel Tube EN10305 - 4 E355 +N For Hydraulic Systems

FAQ:
1. Can you provide a sample to check the quality?
We can provide free sample with same or similar sizes for you to check tube quality.
You need to in charge of Express costs.
2. How about your production capacity?
3000 tons/Month.
3. What are your terms of payment?
30%TT in advance, Balance to be paid before shipment.
4. Where is your factory?
Jiaxing city, 2 hours away from Shanghai.
5. How can I get the quotation A.S.A.P?
Please send us an inquiry with full details as following,quotation will sent to you A.S.A.P:
1). Tube Standard
2). Steel Grade
3). Tube Size and Size Tolerance
4). Tube length
5). Quantity
6). If any special requirements
6. How about the minimum order quantity?
Normally for one size above 1 ton.
Welcome to contact us! Thanks.
