JIS G 3429 Seamless Automotive Steel Tubes for High Pressure Gas Cylinder
JIS G 3429 Seamless Automotive Steel Tubes for High Pressure Gas Cylinder
JIS G 3429 Seamless Automotive Steel Tubes for High Pressure Gas Cylinder
JIS G 3429 Seamless Automotive Steel Tubes for High Pressure Gas Cylinder
JIS G 3429 Seamless Automotive Steel Tubes for High Pressure Gas Cylinder
JIS G 3429 Seamless Automotive Steel Tubes for High Pressure Gas Cylinder
JIS G 3429 Seamless Automotive Steel Tubes for High Pressure Gas Cylinder
JIS G 3429 Seamless Automotive Steel Tubes for High Pressure Gas Cylinder
Specifications
Brand Name :
TORICH
Model Number :
JIS G 3429
Certification :
ISO 9001 ISO 14001 TS 16949
Place of Origin :
China
MOQ :
5TONS
Price :
negotiable
Supply Ability :
15,000 tons per year
Delivery Time :
30-60 days after receive down payment
Packaging Details :
Packed in bundles or wooden box or upon request
Payment Terms :
D/P, L/C, T/T
Product Name :
Seamless Steel Tubes for High Pressure Gas Cylinder
Material :
Manganese，Chrome-molybdenum ，Nickel-molybdenum
Steel Grade :
STH11 STH12 STH21 STH 22 STH31
Standard :
JIS G3429
Dimension :
5-420mm*0.5-50mm*12000mm max
Application :
for High Pressure Gas Cylinder
Production Method :
Seamless
Delivery Condition :
Hot finished ，Cold finished
Description

JIS G 3429 Seamless Automotive Steel Tubes for High Pressure Gas Cylinder

Products Description:

JIS G 3429 Seamless Steel Tubes for High Pressure Gas Cylinder

Well-finished inside and outside surface. Alloy Steel tubes and pipes.

Standard: JIS G 3429 Seamless Steel Tubes for High Pressure Gas Cylinder

Applications: for High Pressure Gas Cylinder

Size Range:

OD: 5-420mm WT: 0.5-50mm

Relevant standard: KS D3573

STEEL GRADE AND CHEMICAL COMPOSITIONS max %

Seel Grade

Class

C

Si

Mn

P

S

Ni

Cr

Mo

STH11

Manganese

Steel tube

0.50max

0.10-0.35

1.80max

0.035max

0.035max

-

-

-

STH12

0.30-0.41

0.10-0.35

1.35-1.70

0.030max

0.030max

-

-

-

STH21

Chrome-molybdenum

steel tube

0.25-0.35

0.15-0.35

0.40-0.90

0.030max

0.030max

0.25max

0.80-1.20

0.15-0.30

STH22

0.33-0.38

0.15-0.35

0.40-0.90

0.030max

0.030max

0.25max

0.80-1.20

0.15-0.30

STH31

Nickel-molybdenum

Steel tube

0.35-0.40

0.10-0.50

1.20-1.50

0.030max

0.030max

0.50-1.00

0.30-0.60

0.15-0.25

Remark:1.Alloying elements not included in Table 2 may be added as required.

2.The chemical composition given in Table 2 shall be similarly applied when product analysis is required by the purchaser

Dimensional Tolerances

OD %

WT %

Tolerance allowance %

L

±1

﹢30

0

20max

﹢30mm

Note: the tolerance is not available for WT＜5.6mmtubes

JIS G 3429 Seamless Automotive Steel Tubes for High Pressure Gas Cylinder JIS G 3429 Seamless Automotive Steel Tubes for High Pressure Gas Cylinder

JIS G 3429 Seamless Automotive Steel Tubes for High Pressure Gas Cylinder JIS G 3429 Seamless Automotive Steel Tubes for High Pressure Gas Cylinder
