Specifications
Brand Name :
Torich
Model Number :
Alloy Steel Pipe Incoloy800HT
Certification :
CE PED
Place of Origin :
China
MOQ :
1000kg
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 tons per year
Delivery Time :
6-8 weeks
Packaging Details :
In bundles in wooden box
Description

B163 Alloy Steel Pipe Incoloy800HT

Incoloy 800HT Chemical composition:

Ni :30.0-35.0

Cr:19.0-23.0

Fe:39.5

C:0.06-0.1

Mn:1.5

Si:1.0

S:0.015

Cu:0.75

Al:0.15-0.60

Ti:0.15-0.60

Metallographic structure:

face-centered cubic structure,The extreme low carbon element content ,improve the rate of Ti:C ,so that it also improve the structural stability, intergranular corrosion resistance.950℃ low temperature annealing assure the crystal structure.

Mechanical properties:

Mechanical properties at room temperature (min)

Product Specification

Yield Strength

RP0.2 N/mm2

Yield Strength

RP1.0 N/mm2

Tensile strength

Rm N/mm2

Elongation

A50%

Brinell hardness

HB

Sheet strip / cold-rolled

Plate / hot rolling

 0.5-6.4

240

 265 585 30 <=2
5-1 135-165

Bar

Cold working

Hot working

 1.6-64
25-1
>1-240 220 250 550 35

Pipe

Cold working

Hot working

 64-240 180 - 530 30 -
5-1

240

 265 585 30

Condenser and heat exchangers		 16-76

High temperature mechanical properties (minimum)

Product Yield Strengt hRP0.2 N/mm2 Yield Strength RP1.0 N/mm2
Temperature ℃ 1 2 3 4 450 1 2 3 4 450
Plate, strip, tube 205 180 170 160 155 235 205 195 185 180
Baton 190 165 155 145 140 220 190 180 170

165

Material feature:

High Nickel content in aqueous corrosion conditions it has good resitance to tress corrosion cracking

High chromium content it has a better resistance to pitting and crevice corrosion cracking

Has excellent corrosion resistance up to 5℃ extremely high temperature aqueous medium

Good resistance to stress corrosion resitance

Good workability

Application:chemical engineering ,power station,petrochemical engineering ect which is exposed

to high temperature corrosivity environment.

Standard:

DIN 17751Tubes of wrought nickel and nickel alloys; properties

DIN4322 Aerospace series - Bolts, double hexagon head with lockwire holes, relieved shank, long thread, in titanium alloy TI-P64001, anodized, MoS coated - Strength class: 1100 MPa (at ambient temperature): German and English version EN 4322:2004

BS 3074:1989 Specification for nickel and nickel alloys: seamless tube

ASTM B423Standard Specification for Nickel-Iron-Chromium-Molybdenum-Copper Alloy (UNS N08825, N08221, and N06845) Seamless Pipe and Tube

SB 423

ASTM B163 Standard Specification for Seamless Nickel and Nickel Alloy Condenser and Heat-Exchanger Tubes

ASTM B704/705

SB 163
