Round Shape Stainless Steel Welded Pipe For Chemical Industry 304 316 310S
Round Shape Stainless Steel Welded Pipe For Chemical Industry 304 316 310S
Round Shape Stainless Steel Welded Pipe For Chemical Industry 304 316 310S
Round Shape Stainless Steel Welded Pipe For Chemical Industry 304 316 310S
Round Shape Stainless Steel Welded Pipe For Chemical Industry 304 316 310S
Round Shape Stainless Steel Welded Pipe For Chemical Industry 304 316 310S
Round Shape Stainless Steel Welded Pipe For Chemical Industry 304 316 310S
Round Shape Stainless Steel Welded Pipe For Chemical Industry 304 316 310S
Specifications
Brand Name :
TORICH
Model Number :
304 316 310S
Certification :
ISO 9001 ISO 14001 TS 16949 EN 10204.3.1 LR KR
Place of Origin :
CHINA
MOQ :
1 TON
Price :
USD 600-800 per ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60000 Tons per year
Delivery Time :
35-45 days
Packaging Details :
In bundles in wooden box
Product name :
Stainless Steel Welded Pipe for Chemical Industry 304 316 310S
Keyword :
Stainless Steel Welded Pipe
Material :
302 ,304,304L,316,316L
Surface :
polish
Type :
Seamless Round Steel Pipe
Application :
fluid transport
Shape :
Round Shape
length :
10-12m
OD :
6-219mm
WT :
2-50mm
Description

Stainless Steel Welded Pipe for Chemical Industry 304 316 310S

Application:Chemical Industry

size:L--10-12m OD--6-219mm WT--2-50mm

steel grade:12Cr18Ni9,06Cr19Ni10 ,022Cr19Ni10,06Cr19Ni10N,06Cr19Ni9NbN,022Cr19Ni10N,06Cr23Ni13,06Cr25Ni20,06Cr17Ni12Mo2,022Cr17Ni12Mo2,07Cr17Ni12Mo2,06Cr17Ni12Mo2Ti

Manufacture method:Hot rolling (squeezing, expanding) or cold drawing (rolling)

Delivery State:Heat treatment and pickling

The Tolerance of Outer Diameter and Wall Thickness Unit:mm

Hot rolling(extrusion,expansion) steel tube Cold drawn(rolling)steel tube
Diamension Tolerance Diamension Tolerance
Ordinary Grade PA High Grade PC Ordinary Grade PA High Grade PC

Nominal Outer Diameter

D

 68~159 ±1.25%D ±1%D

Nominal Outer Diameter

D

 6~10 ±0.20 ±0.15
>10~30 ±0.30 ±0.20
>30~50 ±0.40 ±0.30
>50~219 ±0.85%D ±0.75%D
>159 ±1.5%D >219 ±0.9%D ±0.8%D

Nominal Wall Thickness

S

 <15

+15%S

-12.5%S

 ±12.5%S

Nominal Wall Thickness

S

 ≤3 ±12%S ±10%S
≥15

+20%S

-15%S

 >3

+12.5%S

-10%S

 ±10%S

The Tolerance of Minimum Wall Thickness Unit:mm

Manufacturing Method Diamension Tolerance
Ordinary Grade PA High Grade PC

Hot rolling(extrusion,expansion) steel tube

W-H

 Smin<15

+25%Smin

0

+22.5%Smin

0
Smin≥15

+32.5%Smin

0

Cold drawn(rolling)steel tube

W-C

 All Wall Tickness

+22%Smin

0

+20%Smin

0

Stainless Steel Grade Comparison

No. GB/T 20878-2007 ASTM A 959-09

JIS G4303-2005

JIS G 4311-1991

ISO/TS 15510:2003

ISO 4955:2005

 EN 10088:1-2005

ΓOCT

5632-1972
Unified Digital Code Grade
1 S30210 12Cr18Ni9 S30200,302 SUS302 X10CrNi18-8 X10CrNi18-8,1.4310 12X18H9
2 S30408 06Cr19Ni10 S30400,304 SUS304 X5CrNi18-9 X5CrNi18-10,1.4301 -
3 S30403 022Cr19Ni10 S30403,304L SUS304L X2CrNi19-11 X2CrNi19-11,1.4306 03X18H11
4 S30458 06Cr19Ni10N S30451,304N SUS304N1 X5CrNiN18-8 X5CrNiN19-9,1.4315 -
5 S30478 06Cr19Ni9NbN S30452,XM-21 SUS304N2 - - -
6 S30453 022Cr19Ni10N S30453,304LN SUS304LN X2CrNiN18-9 X2CrNiN18-10,1.4311 -
7 S30908 06Cr23Ni13 S30908,309S SUS309S X12CrNi23-13 X12CrNi23-13,1.4833 -
8 S31008 06Cr25Ni20 S31008,310S SUS310S X8CrNi25-21 X8CrNi25-21,1.4845 10X23H18
9 S31608 06Cr17Ni12Mo2 S31600,316 SUS316 X5CrNiMo17-12-2 X5CrNiMo17-12-2,1.4401 -
10 S31603 022Cr17Ni12Mo2 S31603,316L SUS316L X2CrNiMo17-12-2 X2CrNiMo17-12-2,1.4404 03X17H14M3
11 S31609 07Cr17Ni12Mo2 S31609,316H - - X3CrNiMo17-13-3,1.4436 -
12 S31668 06Cr17Ni12Mo2Ti S31635,316Ti SUS316Ti X6CrNiMoTi17-12-2 X6CrNiMoTi17-12-2,1.4571

08X17H13M2T

Round Shape Stainless Steel Welded Pipe For Chemical Industry 304 316 310SRound Shape Stainless Steel Welded Pipe For Chemical Industry 304 316 310S
