Specifications
Brand Name :
Torich
Model Number :
ISO 2037
Certification :
ISO 9001:2008 , TS16949
Place of Origin :
China
MOQ :
5MT
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
6000MT/Month
Delivery Time :
30~40days
Product Name: :
Stainless Steel Tube
Application: :
For the food industry
Standard: :
ISO 2037
Description

ISO 2037 Stainless steel tubes for the food industry

Application: In food industry

Materials:

Austenitic stainless steels shall be used.

- Seamless tubes: TS47, TS60 and TS61 in accordance with ISO 2604-6:1978

- Weld tubes: TW 47, TW 60 and TW61 in accordance with ISO 2604-4:1978

Surface roughness:

The surface roughness in accordance with the specifications of ISO 468

Fine surface finish Ra ≤ 1 μm

Other surface finish Ra ≤ 2.5 μm

Table 1 Dimension in millimeters

Tube outside diameter

Thickness

12

12.7

17.3

21.3

1

1

1

1

25

33.7

38

1.2 1.6

1.2 1.6

1.2 1.6

40

51

63.5

1.2 1.6

1.2 1.6

1.6

70

76.1

88.9

1.6

1.6

2

101.6

114.3

139.7

2

2

2

168.3

219.1

273

2.6

2.6

2.6

323.9

355.6

406.4

2.6

2.6

3.2

Bibliography:

ISO 1127:1992 Stainless steel tubes - Dimensions, tolerances and conventional masses per unit length

ISO 2604-2:1975 Stainless products for pressure purposes - Quality requirements - Part 2: Wrought seamless tubes

ISO 2604-5:1987, Steel products for pressure purposes - Quality requirements Part 5: Longitudinally welded austenitic stainless steel tubes

ISO 4200:1991, Plain end steel tubes, welded and seamless - General tables of dimensions and masses per unit length
