Specifications
Brand Name :
Torich
Model Number :
API, ASTM, BS, DIN, GB, JIS,
Certification :
GB/T 19001-2008 , ISO 9001:2008 , TS16949
Place of Origin :
China
MOQ :
5Ton
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
6000MT/Year
Delivery Time :
5-8 working days
Packaging Details :
In in hexagonal bundles or wooden box
Grade :
GCr15 SAE52100 100Cr6 SUJ-2 S135 SKF3,SKF3S ECT.
Outer Diameter :
5-114mm
Thickness :
2-20mm
Alloy Or No :
Is Alloy
Section Shape :
Round
Secondary Or Not :
Non-secondary
Application :
rolling bearing/rolling element/Pressure Use
Technique :
Cold Draw or Cold Worked
Delivery Condition :
Black Surface,ff
Description

Seamless Cold Worked Bearing Steel Tube

Bearing Steel Tube 100Cr6 , GCr6 , GCr9(SiMn), GCrl5(SiMn) , GSiMnV(Re),GSiMnMoV(Re),GMnMoV(Re)

Specifications

O.D.: 5-144mm W.T.:3.5-20mm L: 0-12000mm according to customer requirements.

Standard
API, ASTM, BS, DIN, GB, JIS,

Grade
GCr15 SAE52100 100Cr6 SUJ-2 S135 SKF3,SKF3S Etc.

Packing & Delivery
1) In bundles or wooden box
2) 30-40 days

Applications
1) Steel ball, roller and collar of large machinery bearing
2) High-hardness and high contact fatigue strength machinery parts with heavy load, such as axis of rotation, blade, stator pump, profiling, sleeve, mandril, etc.

Characteristics
1) Good hardability and high toughness
2) Long fatigue life
3) Medium cold processing plasticity
4) Certain machinability
5) Poor weldability

The Main Technical Parameter of the finished product

Grade

China

ISO

American

Germany

Japan

England

GCrl5

1

SAE52100

100Cr6

SUJ-2

S135

Chemical Composition

C

Si

Mn

Cr

p

S

Cu

Ni

MO

[O]

0.95
~
1.05

0.15
~
0.35

0.25
~
0.45

1.40
~
1.65

max
0.025


max
0.025


max
0.02


max
0.02


max
0.10


max
10PPM

Surface
Hardness

HB179 ~ 207

Decarbonization
Deepth

Outer Surface

Inner Surface

max0.25mm

max0.25mm

Outside Diameter

φ12mm~φ120mm

Wall
Thickness

2mm~15mm

Dimensions
Tolerance

Outside Diameter

Thickness

Length

Camber

Ellipticity

+0.4mm
-0.00mm

+0.30mm
-0.30mm

3~7m

≤1mm/m

≤0.08

Remarks

The details of dimensions and technical needed as requirement
