ASTM B280 C12200 Seamless Copper Tube for conditioning

This specification covers the requirements for seamless UNS C10200, C12000, or C12200 copper alloy tubes used for connection, repairs, or alternations of field air conditioning or refrigeration units. Materials in the form of billets, bars, or tubes should be used to produce a homogeneous uniform wrought structure by either hot or cold working. Each tube should be cold drawn to the finished size and wall thickness. Coiled lengths with soft annealed tempers should be bright annealed after coiling then dehydrated and either capped, plugged, crimped, or otherwise closed at both ends. Straight lengths with hard drawn tempers should be cleaned and either capped, plugged, or otherwise closed at both ends.

Type: Copper Steel Tube

Application: For Pipeline Transport, Boiler Pipe, Hydraulic/Automobile Pipe

Technique: Cold Drawn

Size:

GENERAL SPECIFICATIONS:

Cleanliness: Bore quality meets the 0.038g/m ASTM B280 specified limit

Material: C12200, Cu 99.9% min, P 0.015 – 0.040%

Mechanical Properties : Tensile Strength: 290 MPa (min) | Elongation: 3% | Hardness: >100 HV

Temper: Hard Drawn

Packaging: Bore internally cleaned and capped

Bending: Not suitable for bending

Length: Manufactured in 10ft lengths, other lengths available on request

Scope

Product Show:
