JIS G 3452 Carbon steel pipes for ordinary piping
JIS G 3452 Carbon steel pipes for ordinary piping
JIS G 3452 Carbon steel pipes for ordinary piping
JIS G 3452 Carbon steel pipes for ordinary piping
JIS G 3452 Carbon steel pipes for ordinary piping
JIS G 3452 Carbon steel pipes for ordinary piping
JIS G 3452 Carbon steel pipes for ordinary piping
JIS G 3452 Carbon steel pipes for ordinary piping
Specifications
Brand Name :
Torich
Model Number :
JIS G 3452
Certification :
IS09001 ISO14001 TS16949
Place of Origin :
China
MOQ :
2 tons
Price :
1100USD/ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000tons per year
Delivery Time :
5-8week days
Packaging Details :
In bundles
Standard :
JIS G 3452
Material :
SDP
Size OD :
10.5-588mm
Length :
12m max
Application :
ordinary piping
Description

JIS G 3452 Carbon steel pipes for ordinary piping

Black pipe without zinc coating

Galvanized pipe with zinc coating

Produce method:

Delivery condition:

Steel Grade:SGP

Relevant standard :KS D 3507 ASTM A 53 API 5L DIN 2440 DIN2441 BS 1387 BS 3601 JIS B 0203 JIS B 0253 JIS B 2301

CHEMICAL COMPOSITION unit (%)
Steel grade P S
SGP 0.040max 0.040max

MECHANICAL PROPERTIES
Steel grade Tensile strength Mpa Elongation%
SGP 290 min 30min

Dimensions weights and Demensional Tolerances
Nominal diameter OD(mm) OD Tolerances WT mm WT Tolerances Unit mass excluding socket kg/m
A B Pipes to be cut in taper thread Other pipes
6 1/8 10.5 ±0.5mm ±0.5mm 2.0

+Not specified

-12.5%

0.419
8 1/4 13.8 ±0.5mm ±0.5mm 2.3 0.652
10 3/8 17.3 ±0.5mm ±0.5mm 2.3 0.851
15 1/2 21.7 ±0.5mm ±0.5mm 2.8 1.31
20 3/4 27.2 ±0.5mm ±0.5mm 2.8 1.68
25 1 34.0 ±0.5mm ±0.5mm 3.2 2.43
32 1 1/4 42.7 ±0.5mm ±0.5mm 3.5 3.38
40 1 1/2 48.6 ±0.5mm ±0.5mm 3.5 3.89
50 2 60.5 ±0.5mm ±1% 3.8 5.31
65 2 1/2 76.3 ±0.7mm ±1% 4.2 7.47
80 3 89.1 ±0.8mm ±1% 4.2 8.79
90 3 1/2 101.6 ±0.8mm ±1% 4.2 10.1
100 4 114.3 ±0.8mm ±1% 4.5 12.2
125 5 139.8 ±0.8mm ±1% 4.5 15.0
150 6 165.2 ±0.8mm ±1.6mm 5.0 19.8
175 7 190.7 ±0.9mm ±1.6mm 5.3 24.2
200 8 216.3 ±1.0mm ±0.8% 5.8 30.1
225 9 241.8 ±1.2mm ±0.8% 6.2 36.0
250 10 267.4 ±1.3mm ±0.8% 6.6 42.4
300 12 318.5 ±1.5mm ±0.8% 6.9 53.0
350 14 355.6 - ±0.8% 7.9 67.7
400 16 406.4 - ±0.8% 7.9 77.6
450 18 457.2 - ±0.8% 7.9 87.5
500 20 508.0 - ±0.8% 7.9 97.4

JIS G 3452 Carbon steel pipes for ordinary piping
