SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper
SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper
SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper
SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper
SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper
SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper
SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper
SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper
Specifications
Brand Name :
TORICH
Model Number :
SAE 1020
Certification :
ISO9001; ISO14001; TSI16949
Place of Origin :
ZheJiang,CHINA
MOQ :
3 tons
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60000 Ton per year
Delivery Time :
30-35 days
Packaging Details :
packing in wooden boxes or in hexagonal bundles
Product name :
SAE1020 1022 Shock Absorber Damper Steel Tube For Automobile
Product Keyword :
Shock Absorber Steel Tube
Grade :
1020
Application :
Auto industry/ machinery use/ Oil Cylinder Tube
Secondary :
Non-secondary
Section shape :
Round
Description

SAE1020 1022 Shock Absorber Damper Steel Tube For Automobile

Size range:

O.D.: 5-420mm W.T.: 0.5-50mm Length: max12000mm

Application:

For Auto industry/ machinery use/ Oil Cylinder Tube/ Motorcycle shock absorber

Steel Grade and Chemical Composition:

AISI SAE 1020 Steel Chemical Composition (%)
UNS Steel Grade C Mn P (≤) S (≤)
G10200 1020 0.18-0.23 0.30-0.60 0.040 0.050

Physical Properties and Mechanical Proporties:

Melting point: 1515 °C (2760 °F)

Density of 1020 steel: 7.87 g/cm3

Material 1020 thermal conductivity
Value (W/m·K) Temperature, °C (°F)
51.9 0 (32)
51.0 100 (212)
48.9 200 (392)
Specific Heat of AISI 1020 Carbon Steel
Value (J/Kg·K) Temperature, °C (°F)
486 50-100 (122-212)
519 150-200 (302-392)
599 350-400 (662-752)
Electrical Resistivity of AISI SAE 1020 Carbon Steel
Value (μΩ·m) Temperature, °C (°F)
0.159 0 (32)
0.219 100 (212)
0.292 200 (392)
AISI SAE 1020 coefficients of linear thermal expansion
Value (10-6/K) Temperature, °C (°F) Treatment
or condition
11.7 20-100 (68-212) Annealed
12.1 20-200 (68-392)
12.8 20-300 (68-572)
13.4 20-400 (68-752)
13.9 20-500 (68-932)
14.4 20-600 (68-1112)
14.8 20-700 (68-1292)

AISI 1020 steel mechanical properties in heat-treated or cold-worked conditions
Steel (UNS) Tensile strength, MPa (ksi) Yield strength, MPa (ksi) Elongation in 50 mm, % Reduction in area, % Hardness (HB) Processing, condition or treatment Sample Size, mm (in.)
1020 (G10200) 380 (55) 205 (30) 25 50 111 Hot rolled 19-31.8 mm (0.75-1.25 in.)
420 (61) 350 (51) 15 41 121 Cold drawn
ASTM AISI SAE 1020 steel mechanical properties in the hot-rolled, normalized, and annealed condition
UNS Grade Tensile strength, MPa (ksi) Yield strength, MPa (ksi) Elongation in 50 mm, % Reduction in area, % Hardness (HB) Processing, condition or treatment Austenitizing temperature, °C (°F) Quenching agent Izod impact strength, J, (ft·lbf) Sample Size
G10200 1020 448 (65) 331 (48) 36 59 143 As-rolled – Oil 87 (64) 12.8 mm (0.505 in.) machined from 25.4 mm (1 in.) rounds.
441 (64) 346.5 (50.3) 35.8 68 131 Normalized 870 (1600) Oil 118 (87)
394.7 (57.3) 295 (43) 36.5 66 111 Annealed 870 (1600) Oil 123 (91)
Cyclic fatigue properties
UNS Grade Cyclic strength coefficient, MPa (ksi) Fatigue strength coefficient, MPa (ksi) Fatigue strength exponent Fatigue ductility coefficient Fatigue ductility exponent Hardness (HB)
G10200 SAE 1020 steel 1205 (175) 850 (123) -0.12 0.44 -0.51 108

SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper

SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper

SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper

SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper

SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper

SAE1020 1022 Automotive Steel Tubes For Shock Absorber Damper

Q: Are you trading company or manufacturer ?

A: A professional steel pipes materials inventor, manufacturer and solution provider

Q: How long is your delivery time?

A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample of ss inox 304 316 Inside and outerside hexagonal pipe for free charge but need pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
