Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder
Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder
Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder
Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder
Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder
Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder
Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder
Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder
Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder
Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder
Specifications
Brand Name :
TORICH
Model Number :
EN 10305-1
Certification :
ISO
Place of Origin :
Zhejiang
MOQ :
5 Tons
Price :
USD 780-850 Per Ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100 Tons Per Month
Delivery Time :
4-6 Weeks
Packaging Details :
Anti Rust Oil Protection, in seaworthy packing
Section shape :
Round
Alloy or not :
Non-alloy
Technique :
Cold Drawn
Thickness :
4 - 50 mm
Standard :
DIN,ASTM,GB,JIS,API
Outer diameter(round) :
30 - 250 mm
Description
EN 10305-1 Oil Gas Sewage Transport Seamless honed precision steel tube for hydraulic cylinder
Type:Hydraulic Cylinder Tube

I.D.: 40-400mm

W.T.: ≥5mm

Technique: Cold Draw

Alloy Or Not: Non-alloy

Place Of Origin: Zhejiang, China (Mainland)

Surface Treatment: As Customer's Required

Length: Up To 12000mm According To Customer's Requirement
Material: 20#,45#,Q345B,Q345D,25Mn,27SiMn,E355

Standard: GB/T3639, GB/T8713, EN10305-1:2002, EN10305-2:2002, ASTM A519-2006, ASTM A513-2007, GB/T1591-2008, GB/T17396-2009

Applications:

for Auto industry

for machinery use

Oil Cylinder Tube

Motorcyle shock absorber
Auto shock absorber innder cylinder

Telescopic Cylinders

Size range:

ID.: 20-650mm W.T.:1-50mm L:max12000mm

Steel Grade:

E155, E195, E235, E275, E355. S45C

Steel Grade and Chemical Compositions

Steel Grade C Si Mn P S
Steel Name Steel Number max max max max max
E155 1.0033 0.11 0.35 0.70 0.025 0.025
E195 1.0034 0.15 0.35 0.70 0.025 0.025
E235 1.0308 0.17 0.35 1.20 0.025 0.025
E275 1.0225 0.21 0.35 1.40 0.025 0.025
E355 1.0580 0.22 0.35 1.60 0.025 0.025

Heat treatment method:

+Cc, +LCc, +SR, +Ad, +N


Note: Special steel grade is also available, according to customer request.

Please specify the steel grade and heat treatment mothod when sending the enquiry!

ID Honing

Utilize an abrasive stone,which turns while being moved in and out of the work piece.

The honing process makes :

1.Smooth surface finishes inside bores

2.Hold precise tolerances on bore diameters

ID H7 H8 H9

ID roughness 0.2-0.8μm

ID max 630mm

Roller Burnish+ Skiving

Two thin chips are cut at high feed rate while the tool passes through the workpiece.producing super finish surface,with a bore precise tolerance .

ID H7 H8 H9
ID roughness 0.2-0.8μm

ID max 630mm

QUALITY CONTROL

1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing and Cold Rolling, on line inspection
5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
6. Straightening-Cutting to specified length-Finished Measuring Inspection
7. Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8. Packing and Stocking.

100% of our steel tubes are dimensionally checked
100% of our steel tubes are visually checked to assure they have a perfect surface condition and no surface defects.
100% eddy current test and ultrosonic test to eliminate longitudinal and transversal defects.

Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder

Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder

Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder

Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder

Transport Seamless Honed Precision Steel Tube Oil Gas Sewage For Hydraulic Cylinder

Packing Details : In bundles or in wooden boxes packaging of honed tube

Delivery Details : 30-60days

In hexagonal bundles packaging with woven

In hexagonal shaps,the tubes will be well fixed,so it can avoid the damages when delievey .

In wooden boxes.

Solid packaging ,protecting tubes from damages much better.
In poywooden packaging,It cut the packaging costs also it can protect tubes well
