DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose
DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose
DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose
DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose
DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose
DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose
DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose
DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose
DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose
DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose
Specifications
Brand Name :
TORICH
Model Number :
DIN 2458 ST37.2
Certification :
ISO 9001 ISO14001 TS16949
Place of Origin :
Zhejiang/China
MOQ :
1 Ton
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60000 Ton/Tons per Year
Delivery Time :
20-40days
Packaging Details :
In bundles or in wooden boxes.
Section shape :
Round/Square/Rectangular/Oval.etc
Secondary or not :
Non-secondary
Technique :
ERW,Cold Drawn,Extruded
Thickness :
0.4 - 50 mm
Application :
General Purpose
Surface treatment :
Galvanized
Alloy or not :
Non-alloy,Is Alloy
Standard :
ASTM,GB,JIS,BS
Grade :
ST37.2
Standard2 :
DIN 2458
Special pipe :
API Pipe,EMT Pipe
Length :
1-12m/as customers' requests
Surface :
Galvanized Coated
Outer diameter(round) :
20 - 677 mm
Product name :
ERW steel pipes,galvanized round pipe
Description

DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose

DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose

Material

DIN 2458 ST37.2 is a standard specification for welded round tubes made from low carbon steel. This material is commonly used in various engineering and construction applications due to its excellent weldability and machinability.

Specification

The specification outlines the requirements for ERW (Electric Resistance Welded) steel tubes, which are produced by welding flat steel strips into a tubular shape. The tubes are characterized by their round cross-section and are available in various diameters and wall thicknesses.

Key Features

  • Weldability: Excellent for welding processes.
  • Machinability: Suitable for machining operations.
  • Versatility: Applicable in various industries including construction, automotive, and manufacturing.
  • Cost-Effective: Economical choice for general-purpose applications.

Chemical Composition

Element Composition (%)
Carbon (C) 0.12 - 0.20
Manganese (Mn) 0.30 - 0.60
Phosphorus (P) ≤ 0.045
Sulfur (S) ≤ 0.045
Silicon (Si) ≤ 0.40
Iron (Fe) Balance

Mechanical Properties

Property Value
Yield Strength (Rp0.2) ≥ 235 MPa
Tensile Strength (Rm) 370 - 510 MPa
Elongation (A) ≥ 26%
Hardness (HB) ≤ 160

Steel Grade

The steel grade for DIN 2458 ST37.2 is classified as S235JR according to EN 10025, which indicates its suitability for structural applications.

Application

DIN 2458 ST37.2 welded round tubes are widely used in:

  • Structural applications in buildings and bridges.
  • Manufacturing of machinery and equipment.
  • Automotive components.
  • General engineering applications.

Possible Alternative Grades

  • S235JRG2: Similar mechanical properties, suitable for structural applications.
  • S275JR: Higher yield strength, used in more demanding applications.
  • ST52.0: Offers higher tensile strength for specialized applications.

DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose

DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose

DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose

DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose

DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose

TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.
The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.
The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.
Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.

DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose

DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose

DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose

DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose

DIN 2458 ST37.2 Welded Round Tube ERW Welded Steel Tube For General Purpose

Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.

Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
