Specifications
Brand Name :
TORICH
Model Number :
DIN 17172
Certification :
ISO,ISO9001-2008,ISO9001
Place of Origin :
Zhejiang/China
MOQ :
1 Ton
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60000 Ton/Tons per Year
Delivery Time :
20-40days
Packaging Details :
In bundles or in wooden boxes.
Application :
Flammable Gas Transportation
Standard :
ASTM,DIN,GB,JIS
Thickness :
0.1mm-60mm
Technique :
Cold Drawn,Hot Rolled,Cold Rolled,Hot Rolled/Cold Drawn
Surface treatment :
customerized
Grade :
StE 210.7 StE 240.7 StE 290.7 StE 320.7 StE 360.7 StE 385.7 StE 415.7 StE 290.7 TM StE 320.7 TM StE 360.7 TM StE 385.7 TM StE 415.7 TM StE 445.7 TM StE 480.7 TM
Alloy or not :
Is Alloy,NON -alloy
Section shape :
Round,Rectangular
Outer diameter(round) :
17 - 660 mm
Special pipe :
Thick Wall Pipe,Precision steel tube,precision seamless pipe,cold drawn
Secondary or not :
Non-secondary
Length :
6M or as requirement
Product name :
steel tubes
Type :
Seamless
Material :
steel
Description

DIN 17172 StE 210.7 Gas Steel Pipe Low Alloy Long Distance For Flammable Gas Transportation

DIN 17172 StE 210.7 StE 240.7 StE 290.7 StE 320.7 StE 360.7 Gas Steel Pipe Low Alloy Long Distance For Flammable Gas Transportation

Introduction

DIN 17172 is a standard that specifies the requirements for low alloy steel pipes used in the transportation of flammable gases over long distances. The grades StE 210.7, StE 240.7, StE 290.7, StE 320.7, and StE 360.7 are designed to provide excellent mechanical properties and corrosion resistance, making them suitable for various applications in the gas industry.

Material Specification

The materials used in the production of these steel pipes must meet specific chemical and mechanical properties to ensure safety and reliability in gas transportation.

Key Features

  • Low Alloy Composition: Enhances strength and toughness.
  • High Weldability: Suitable for various welding techniques.
  • Corrosion Resistance: Provides durability in harsh environments.
  • High Strength: Capable of withstanding high pressures.

Chemical Composition

Steel Grade C (%) Si (%) Mn (%) P (%) S (%) Cr (%) Ni (%) Mo (%)
StE 210.7 0.10 0.20 1.20 0.025 0.015 0.30 0.30 0.10
StE 240.7 0.12 0.25 1.40 0.025 0.015 0.40 0.40 0.15
StE 290.7 0.14 0.30 1.50 0.025 0.015 0.50 0.50 0.20
StE 320.7 0.16 0.35 1.60 0.025 0.015 0.60 0.60 0.25
StE 360.7 0.18 0.40 1.70 0.025 0.015 0.70 0.70 0.30

Mechanical Properties

Steel Grade Yield Strength (MPa) Tensile Strength (MPa) Elongation (%) Impact Toughness (J)
StE 210.7 210 350 22 27
StE 240.7 240 370 20 27
StE 290.7 290 400 18 27
StE 320.7 320 430 16 27
StE 360.7 360 460 14 27

Steel Grade

The steel grades StE 210.7, StE 240.7, StE 290.7, StE 320.7, and StE 360.7 are categorized based on their yield strength and chemical composition, making them suitable for various applications in the gas transportation sector.

Application

These steel pipes are primarily used in:

  • Natural Gas Transportation: Long-distance pipelines for natural gas.
  • Flammable Gas Distribution: Infrastructure for distributing flammable gases.
  • Industrial Applications: Used in various industries requiring safe gas transportation.

Possible Alternative Grades

While DIN 17172 grades are widely used, alternative grades may include:

  • API 5L: Suitable for oil and gas pipelines.
  • ASTM A106: Commonly used for high-temperature service.
  • EN 10208: European standard for gas pipelines.
