Prefabricated Steel Structure Workshop Galvanized Surface Z Section Long Life Span
Prefabricated Steel Structure Workshop Galvanized Surface Z Section Long Life Span
Prefabricated Steel Structure Workshop Galvanized Surface Z Section Long Life Span
Prefabricated Steel Structure Workshop Galvanized Surface Z Section Long Life Span
Prefabricated Steel Structure Workshop Galvanized Surface Z Section Long Life Span
Prefabricated Steel Structure Workshop Galvanized Surface Z Section Long Life Span
Specifications
Brand Name :
Homeshore
Model Number :
CAGJG-004
Certification :
ISO9001
Place of Origin :
China
MOQ :
100 square meters
Price :
Negotiation
Payment Terms :
T/T, Western Union,, L/C
Supply Ability :
1500 ton per Month
Delivery Time :
20-30 working days
Packaging Details :
Standard export packing
Wall and roof :
Color Steel Sandwich Panel
Surface Treatment :
Painted or Galvanized
Type :
Heavy
Purlin :
C/Z Galvanized Steel (Q235)
Color :
Optional as Client requrest
Door :
Electric Shutter Door
Description

Galvanized Z Section Steel Prefabricated Steel Structure Workshop With Long Life Span

Information of the structure and its materials:

The steel structure is divided into two parts, the main one consisting of beams and columns (usually I section, depending on the project) which make up the structural portals; and the secondary consisting of galvanized purlings (C or Z sections) and steel tensioners which give rigidity to the structure and at the same time serve as an anchor for the walls and the roof. Generally the main structure has two layers of anti-rust paint, but if necessary they can be galvanized.

Product Description:

Product Information
Column and beam Welding steel and hot-roll steel
Steel surface treatment painted(mid-grey)
Steel grade Q235B
Purlin and girt C section steel
Conection Method All bolt connection,easy installation
Wall&Roof Metal sheet with blue,red,whitegrey color
Door Rolling shutter door
Window Aluminum alloy window
Bolt and nuts High Strength Bolt and ordinary bolt
Design life span 50 years
Place of origin Qingdao city,Shandong province, China (Mainland)
Business type Manufacture and trading
Packaging Details Bunding with pallet or customize

Prefabricated Steel Structure Workshop Galvanized Surface Z Section Long Life Span

Drawing:


Prefabricated Steel Structure Workshop Galvanized Surface Z Section Long Life Span

The walls and roof may be composed of a galvanized sheet steel system with glass wool or sandwich panels. In a standard way they are quoted with a thickness of 50mm. Available thicknesses: 50 mm, 75 mm, 100 mm, 150 mm, 200 mm. Densities between 80 -120 kg m3.

Screws, nuts, brackets, anchor bolts and other inputs are quoted in the budget.

Prefabricated Steel Structure Workshop Galvanized Surface Z Section Long Life Span

Quality control:

General fabrication main process of steel structure is divided into: material preparation →cutting→ assembling→ welding→ drilling → assembly → correction → shot blasting and rust removal → painting → number →component acceptance ex-factory. In the steel structure production, according to the steel structure production process flow, grasp the key processes for quality control, such as control of key parts processing, main components of the process, measures, processing equipment, process equipment, etc. Each processing part, we can have strict inspection specifications. Welding engineering is the most important link in steel structure fabrication and installation engineering.

For the welding, We have our qualified CWI welding inspector to control the quality according to AWS-D1.1/D1.5 welding quality system. Spot welding strictly weld according to ASW welding quality system.


Manufacturing, packing & shipping and payment terms:

Once the advance payment is made, the manufacturing of the structure begins. Depending on the size of the project, production takes between two and four weeks. The packed structure is loaded in containers 40 'HQ open top to facilitate loading and unloading. Ways of payment: T / T (30% advance, 70% before boarding) or L / C.


Application:


Prefabricated Steel Structure Workshop Galvanized Surface Z Section Long Life Span
