Anti Fire / Rust Prefab Corrugated Metal Buildings , Painted Prefabricated Engineered Building
Anti Fire / Rust Prefab Corrugated Metal Buildings , Painted Prefabricated Engineered Building
Anti Fire / Rust Prefab Corrugated Metal Buildings , Painted Prefabricated Engineered Building
Anti Fire / Rust Prefab Corrugated Metal Buildings , Painted Prefabricated Engineered Building
Anti Fire / Rust Prefab Corrugated Metal Buildings , Painted Prefabricated Engineered Building
Anti Fire / Rust Prefab Corrugated Metal Buildings , Painted Prefabricated Engineered Building
Specifications
Brand Name :
Homeshore
Model Number :
CAGJG-0010
Certification :
ISO9001
Place of Origin :
China
MOQ :
300 square meters
Price :
Negotiation
Payment Terms :
T/T, Western Union,,
Supply Ability :
10000 square meters per month
Delivery Time :
20-30 working days
Packaging Details :
Standard export packing
MOQ :
200 Square meters
Surface Treatment :
Painted
Connect :
Bolt connect
Purlin :
C.Z Shape Steel Channel
Drawing Design :
Auto CAD
Product name :
Prefab Steel Structures
Description

Fast Construction Fire Proof and Rust Proof Galvanzied Z Section Steel Prefabricated Structure



What is the Steel Structure ?


Steel structure building is a type of construction with load-bearing structure made of construction steel. Beams, columns, trusses and other components usually made of shaped steel and steel plates constitute a load-bearing structure. It forms a whole building with the Maintenance system such as roof panel, floor panel and wall panel.

Brief Description:
Pre engineered steel structure building is a Green economy building system, which is formed by the main
structure (H-section steel for beam/column, C channel steel or Z channel steel for purlin), substructure
(Round steel bar or Angle steel for bracing, Round steel tube for tie bar, Angle steel for angle brace), roof
and wall system (using sandwich panel or single steel sheet), door and window system. Pre engineered steel
structure building building is widely used as warehouse, workshop, hangar, shed, etc..

Anti Fire / Rust Prefab Corrugated Metal Buildings , Painted Prefabricated Engineered Building
Product Description:

Items Specification
Main Steel Frame Column Q235, Q345 Welded H Section Steel
Beam Q235, Q345 Welded H Section Steel
Secondary Frame Purlin Q235 C and Z purlin
Knee brace Q235 Angle Steel
Tie rod Q235 Circular Steel Pipe
Brace Q235 Round Bar
Vertical&Horizontal support Q235 Angle Steel, Round Bar or Steel Pipe
Maintenance system Roof panel EPS Sandwich Panel / Glass Fiber Sandwich Panel /
Rock Wool Sandwich Panel / Pu Sandwich Panel /Steel Sheet
Wall panel Sandwich Panel / Corrugated Steel Sheet
Accessories Window Aluminiumn Alloy Window / PVC Window / Sandwich Panel Window
Door Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door
Rainspout PVC
Live load on Roof In 120kg/Sqm (Color steel panel surrounded)
Wind Resistance Grade 12 Grades
Earthquake-resistance 8 Grades
Structure Usage Up to 50 years
Finishing Options Vast array of colors and textures available
Paint Options Alkyd paiting, two primary painting, two finish painting
(gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized.



Anti Fire / Rust Prefab Corrugated Metal Buildings , Painted Prefabricated Engineered Building

Accessories:

Anti Fire / Rust Prefab Corrugated Metal Buildings , Painted Prefabricated Engineered Building


Packaging & Shipping:
All the structure components, panels, bolts and sorts of accessories will be well packed with standard package suitable for ocean transport and loaded into 40'ot.
All the products are loaded at the loading site of our factory using crane and forklift byour skilled workers, who will prevent the goods to be damaged.
Good relationship with many vessel companies to make sure the transportation smooth

Application:

Anti Fire / Rust Prefab Corrugated Metal Buildings , Painted Prefabricated Engineered Building
