Specifications
Brand Name :
EMSCO
Model Number :
F1000
Certification :
API
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
2000 pieces per minth
Delivery Time :
10 days
Price :
USD
Packaging Details :
WOODEN BOX
Usage :
Oil,drill rig
Power :
Electric,diesel
Pressure :
High Pressure,Low Pressure
Application :
Conveying mud and flushing fluids,mining,oil
Structure :
Piston Pump,Single-stage Pump,centrifugal mud suction pump
Fuel :
Diesel
Standard or nonstandard :
Standard
Type :
Mud Pump
Weight :
100-3700kg
Color :
red and so on,Green,Green or per customer design
Material :
cast iron/stainless steel mud suction pump,Chrome alloy,Stainless steel aluminum plastic etc
Warranty :
12 Months
Feature :
Compact Size
Product name :
Mud Pump
Head :
10m mud suction pump
Oem :
can be accept,Applicable
Condition :
new
Description

www.premiumrigparts.com

EMSCO F1000 mud pump Piston and valve， F1600 mud pump, National 12P160 mud pump, 14P220 mud pump, PZ9 mud pump, PZ8 pumpEMSCO F1000 mud pump Piston and valve， F1600 mud pump, National 12P160 mud pump, 14P220 mud pump, PZ9 mud pump, PZ8 pump

CONTINENTAL EMSCO F-1000, F800 FLUID END MODULE

ITEM # OEM PART # MISSION PART # DESCRIPTION
1 EMSFEMF1000CA ASSY, COMPLETE FLUID END MODULE (INCLUDES ITEMS 1A-22)
1A 0-6999-0086-02 EMSFEMF1000 MODULE, STUDDED FLUID END (INCLUDES ITEMS 1A-7)
1B 80723010 MODULE, STUDDED FLUID END MADE FROM 4135 MATERIAL (INCLUDES ITEMS 1B-7)
2 0-7507-2205-00 EMSF1000PFS STUD, POWER FRAME
3 0-7601-0630-17 EMSF1000PFSN NUT, POWER FRAME STUD
4 0-7507-2150-00 EMSF1000TRS STUD, THREADED RING
5 0-7601-0630-28 EMSF1000TRSN NUT, THREADED RING STUD
6 0-7507-2108-00 EMSF1000DMS STUD, DISCHARGE MANIFOLD
7 0-7601-0630-24 IDT800TRSN NUT, DISCHARGE MANIFOLD STUD
8 0-6319-0026-00 EMSF1000LC CAGE, LINER
9 0-6319-0087-00 EMSF1000LVG GUIDE, LOWER VALVE (WITH BUSHING)
10 0-6319-0089-00 EMSF1000LVC CLIP, LOCKING (FOR LOWER VALVE GUIDE)
11 0-7602-2200-32 7918282 GASKET, LINER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS)
12 0-6319-0031-00 EMSF1000CYHPLG PLUG, CYLINDER HEAD
13 0-6999-0089-00 EMSF1000CYHFLG RING, THREADED CYLINDER HEAD
14 0-6319-0090-00 EMSF1000CYHCAP CAP, THREADED CYLINDER HEAD
15 7916740 7916740 GASKET, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS)
16 0-7501-0051-00 PEP79 SCREW, RETAINER (UPPER)
17 0-6397-0603-00 EMSRETAINER RETAINER PLATE (UPPER)
18 0-6397-0575-00 EMSF1000UVGB GUIDE, UPPER VALVE
19 0-6319-0027-00 EMSF1000CAP COVER, VALVE POT
20 0-7602-1610-46 0-7602-1610-46 GASKET, DISCHARGE MANIFOLD
21 0-7602-1600-61 0-7602-1600-61 GASKET, SUCTION MANIFOLD
22 0-6316-0096-00 EMSF1000LVGB BUSHING, LOWER VALVE GUIDE
23 0-7601-0336-00 0-7601-0336-00 CAPSCREW, SUCTION MANIFOLD - NOT SHOWN
7924503 MODULE SEAL KIT: (KIT INCLUDES SUCTION MANIFOLD O-RING, DISCHARGE MANIFOLD O-RING, CYLINDER HEAD GASKET, VALVE COVER GASKET)

All our fluid end parts are manufactured to API 7K quality standards.

Parts are available for these popular pump models:

BOMCO/Emsco Mud Pumps:F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,

LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600
Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,
National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,
Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,

Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT

Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200

Russian Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32

WEATHERFORD/Ellis Williams: E-447, E-2200

Drillmec: 9T1000, 12T1600, 7TS600, 7TS500, 9T800

Romania: 3PN-1000, 3PN-1600, 3PN-2000

And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.
