Specifications
Brand Name :
Emsco, National, Southwest, Gardner Denver
Model Number :
HHF1600, HHF1300, HHF1000, HHF800, HHF500
Certification :
API 7K
Place of Origin :
CHINA
MOQ :
1 piece
Price :
1 to 500 usd
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
3000 pieces per month
Delivery Time :
In stock
Packaging Details :
Suitable to shipment by sea and air
Usage :
Oil,Water,drill rig
Power :
Electric,Hydraulic,diesel
Pressure :
High Pressure,Low Pressure
Application :
mining,oil,Chemical
Structure :
Piston Pump
Fuel :
Diesel,Electric
Standard or nonstandard :
Standard
Type :
Mud Pump
Color :
Green or per customer design
Material :
cast iron/stainless steel mud suction pump,Chrome alloy
Warranty :
12 Months
Product name :
Mud Pump
Oem :
Applicable
Condition :
new
Description

Honghua HHF1300/1600 mud pump， HHF1000 mudp ump, HHF800 mud pump, HHF500 mud pump Liners, Pistons, Valves, Fluid end

No. P/N Description Qty Drawing Code
1 11-3101-0501-00　　 Cylinder assembly 3 GH3101-05.01.00
2 11-3101-0502　　 Cylinder Cover, Threaded ring 3 GH3101-05.02
3 11-3101-0503　　 Cylinder Cover, 3 GH3101-05.03
4 11-3101-0504　　 Seal ring, cylinder cover 6 GH3101-05.04
5 11-3101-0505　　 Plug, cylinder cover 3 GH3101-05.05
6 11-3101-0506 Puller 3 GH3101-05.06
7 B34521-975-355-69　 O-ring, 97.5×3.55G 3 GB/T3452.1-1992
8 11-3101-0507　　 Blind plate, discharge, 5 1/8" 1 GH3101-05.07
9 11-3101-0508　　 Discharge manifold 1 GH3101-05.08
10 11-3101-0509　　 Seal ring, valve cover 3 GH3101-05.09
11 11-3101-0510 Stud, 1 1/2-8UN-2A*262 16 GH3101-05.10
12 11-3101-0501-03　 Nut, 1 1/2-8UN-2B(SPL) 32 GH3101-05.01.03
13 11-3101-0511　　 Valve cover 3 GH3101-05.11
14 11-3101-0512　　 Guide, valve stem 3 GH3101-05.12
15 11-3101-0513-00　　 Spring guide 3 GH3101-05.13.00
16 11-3101-0514　　 Baffle 3 GH3101-05.14
17 11-3101-0515 Bolt, 3/8-16UNC-2A*20 12 GH3101-05.15
18 11-3161-0545　 Stainless steel wire, φ1.60(L=1830) 1 GB/T4240-1993
19 11-3101-0516　 Valve spring 6 GH3101-05.16
20 11-3101-0517-00　 Valve assembly,(API 6#) 6 GH3101-05.17.00
21 11-3101-0518-00　 Nut, piston 3 GH3101-05.18.00
22 11-3101-0519-00-1　 Piston 3 GH3101-05.19.00A
23 11-3101-0520　　 Seal ring, piston 3 GH3101-05.20
24 11-3101-0521 Piston rod 3 GH3101-05.21
25 11-3101-0522-01-1 Ordinary liner 4 3/4 3 GH3101-05.22A
11-3101-0522-02-1 Ordinary liner 5
11-3101-0522-03-1 Ordinary liner 5 1/2
11-3101-0522-04-1 Ordinary liner 6
11-3101-0522-05-1 Ordinary liner 6 1/4
11-3101-0522-06-1 Ordinary liner 6 1/2
11-3101-0522-07-1 Ordinary liner 6 3/4
11-3101-0522-01 Bi-metal liner 4 3/4 GH3101-05.22
11-3101-0522-02 Bi-metal liner 5
11-3101-0522-03 Bi-metal liner 5 1/2
11-3101-0522-04 Bi-metal liner 6
11-3101-0522-05 Bi-metal liner 6 1/4
11-3101-0522-06 Bi-metal liner 6 1/2
26 11-3101-0523-00　　 Spraying pipe assembly 1 GH3101-05.23.00
27 11-3101-0524-00　　 Clamp assembly, piston rod 3 GH3101-05.24.00
28 11-3101-0525　　 Splash Shield, liner 3 GH3101-05.25
29 11-3101-0526 Fixing clamp 3 GH3101-05.26
30 11-3101-0527-00　　 Guide, valve stem(lower) 3 GH3101-05.27.00
31 B34521-190-700-69　 O-ring, 190×7.0G 3 GB/T3452.1-1992
32 11-3101-0536　 Bolt, 7/8-9UNC-2Ax55 18 US standard
33 11-3101-0528-00　　 Suction manifold 1 GH3101-05.28.00
34 11-3101-0529-00　　 Suction dampener 1 GH3101-05.29.00
35 11-3101-0530-00　 Shims 4 GH3101-05.30.00
36 11-3161-0544　 Bolt, 1 1/16-8UN-2A*90 36 US standard
37 11-3161-0543　 Nut, 1 1/16-8UN-2B(SPL) 36 US standard
38 B34521-345-700-69　 O-ring, 345×7.0G 3 GB/T3452.1-1992
39 11-3101-0531　　 Suction flange(Ⅰ) 1 GH3101-05.31
40 11-3101-0532　　 Suction flange(Ⅱ) 1 GH3101-05.32
41 11-3101-0533　　 Plug screw, NPT1 1/2 1 GN3101-05.33
42 11-3101-0534 Washer, 39 24 GH3101-05.34
43 11-3101-0535 Blind plate, suction inlet, 12" 1 GH3101-05.35

Honghua HHF1300/1600 mud pump， HHF1000 mudp ump, HHF800 mud pump, HHF500 mud pump Liners, Pistons, Valves, Fluid end

All our fluid end parts are manufactured to API 7K quality standards.

Parts are available for these popular pump models:

BOMCO/Emsco Mud Pumps:F2200HL, F1600HL, F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,

LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600


Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,


National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,


Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,

Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT

Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200

Russian Mud Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32

WEATHERFORD/Ellis Williams: E-447, E-2200

Drillmec Mud Pump: 9T1000, 12T1600, 7TS600, 7TS500, 9T800

Romania Mud Pump: 3PN-1000, 3PN-1600, 3PN-2000

And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.
