AA3105 H47 0.7mm Thick Painted Aluminum Coil Used In Rain Water Guttering System
AA3105 H47 0.7mm Thick Painted Aluminum Coil Used In Rain Water Guttering System
AA3105 H47 0.7mm Thick Painted Aluminum Coil Used In Rain Water Guttering System
AA3105 H47 0.7mm Thick Painted Aluminum Coil Used In Rain Water Guttering System
AA3105 H47 0.7mm Thick Painted Aluminum Coil Used In Rain Water Guttering System
AA3105 H47 0.7mm Thick Painted Aluminum Coil Used In Rain Water Guttering System
AA3105 H47 0.7mm Thick Painted Aluminum Coil Used In Rain Water Guttering System
AA3105 H47 0.7mm Thick Painted Aluminum Coil Used In Rain Water Guttering System
Specifications
Brand Name :
Dingang
Model Number :
Dingang - PPAL
Certification :
SGS,ITS,BV
Place of Origin :
China
MOQ :
1000 Kgs / 1 Metric Ton
Price :
Negotiable
Payment Terms :
T/T,L/C
Supply Ability :
5000 Tons / Per Month
Delivery Time :
Within 35 Days After Order Confirmed And Down Paymetn Received
Packaging Details :
Seaworthy Packing With Wooden Pallet
Product name :
prepainted aluminium sheet
Alloy :
AA3003 , 3004 , 3105
Temper :
O , H12 , H14 , H16 , H18 , H24 , H26 , H32 , H34 , H111 , H112 , T3 , T5 , T6 etc
Application :
Construction,roofing,Decoration,Building,etc.
Sample :
Avaliable
Type :
Color Coated Aluminum Sheet/ Coil
Description

AA3105 H47 0.7mm Thick Painted Aluminum Coil Used In Rain Water Guttering System

Description of prepainted aluminium :
Color coated aluminum ( prepainted aluminum ) , which is produced with aluminum sheet or coil and processed by coating with color or pattern.
In common sense , here are two kinds of coating PVDF and PE . Compared with other section steel prepainted aluminum coil is the more popular material , because of its excellent property. Firstly the property is very stable so the surface is erosion resistant , warranty could up to 30 years long after special treatment . Then , the density is the lowest among metal material when volume is fixed .

Specifications :
Alloy : AA1050 , 1060 , 1100 , 3003 , 3004 , 3105 , 5052 , 5005 , 5754 , 5083 , 6061 , 6063 , 8011 Etc
Temper : O / H16 / H18 / H22 / H24 ( All According Customers' Requirement )
Standard : ASTM , ASME , AISI , JIS , DIN , EN , ISO , GB And Etc
Thickness : 0.1 mm - 2.5 mm
Width : 30 - 2500 mm
Thickness Paint Layer : ( PVDF ) more than 25 micron ; ( PE ) more than 18 micron
Interior Diameter : 405 mm , 505 mm , 150 mm etc
Color : Ral Color Code Or As Per Clients Requirements And Sample
Coating Hardness : More Than 2H ( pencil hardness )
Impact Resistance : No Cracking And Peeling ( 50kg / cm , ASTMD - 2794 : 1993 )
Flexibility ( T-bend ) : No More Than 2T
MEK Resistance : More Than 100

Alloy3003 , 3004 , 3105 TemperO , H12 , H14 , H16 , H18 , H24 , H26 , H32 , H34 , H111 , H112 , T3 , T5 , T6 Etc
Coating TypePE Or PVDFInterior Diameter508 mm
Material Width300mm 350mm 380mmMaterial Thickness0.5 - 2.5mm
Color OptionRal Color Code Or As Per Clients Requirements And Sample


Paint Performance of prepainted aluminium :

Test ItemPaint
PVDFPE And Others
With VarnishWithout Varnish
Paint Film Thickness , μ≥ 22≥ 30≥ 18
Shine ToleranceShine ≥ 80 Unit , ± 10 Unit Allowed
Shine ≥ 20-80 Unit , ± 7 Unit Allowed
Shine < 20 Unit , ± 5 Unit Allowed
Pencil Hardness≥ 1H
Abrasion Resistance, L/μm≥ 5--
T-bend≤ 2T≤ 3T
Impact Strength50KG . CM Without Depainting And Crack
Adhesive Force ( Class )≥ 1
Boiling Water ResistanceUnvarying
Chemical ResistanceAcid EnduranceUnvarying
Alkali StabilityUnvarying
Oil ResistivityUnvarying
Resistance To Solvent≥ 70≥ 50
Scrub Resistance≥ 10000 Times Unvarying
Dirt Resistance≤ 15 %--
Salt Spray Resistance ( class )≥ 2 class--



Packing :


Export Standard Seaworthy Packing With Wooden Pallets In Horizontal Or Vertical (As Per The Requirements Of Clients)
