Specular Laminate Aluminum Mirror Sheet For Reflector Plate Of Solar Energy
Specular Laminate Aluminum Mirror Sheet For Reflector Plate Of Solar Energy
Specular Laminate Aluminum Mirror Sheet For Reflector Plate Of Solar Energy
Specular Laminate Aluminum Mirror Sheet For Reflector Plate Of Solar Energy
Specular Laminate Aluminum Mirror Sheet For Reflector Plate Of Solar Energy
Specular Laminate Aluminum Mirror Sheet For Reflector Plate Of Solar Energy
Specifications
Brand Name :
Dingang
Model Number :
Dingang - MA / RA
Certification :
SGS , BV , ITS
Place of Origin :
China
MOQ :
500 Kilograms
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5 000Metric Tons Per Month
Delivery Time :
Within 15-20 Days After Order Is Confirmed
Packaging Details :
Standard Seaworthy Packing With Wooden Pallet
Product Name :
Aluminum Mirror Sheet
Surface Treatment :
Laminate , Polished , Anodized
Aluminum Alloy :
AA1060 , 1085 , 3003 , 5052 , 8011 And Etc
Aluminum Thickness :
0.17 - 1.50 mm
Aluminum Width :
30 - 1500 mm ( Usual 1000 mm , 1200 mm , 1250 mm )
Useful Life :
10 Years Indoor , 2 Years Outdoor Under Sunshine
Surface Reflectivity :
Reach 86 % , Diffuse Reflection Less Than 12 %
aluminum Material :
1060 , 1085 , 3003
Strength Of Adhesive :
Meet Requirements Of GB 2794 - 81 - 84
Description



Specular Laminate Aluminum Mirror Sheet For Reflector Plate Of Solar Energy
Profile :
Aluminum Mirror Finish Sheet , we also called it Reflective Aluminum Sheet . The base material is bare aluminum sheet , and then we make a special treatment on the surface of aluminum sheet and stick a layer of high quality reflective material . The production are well and widely used in lights and lampshade , grille lamp line .

Brand NameDingang
StandardGB 2794 - 81 - 84
Alloy:1060 3003 1085
Thickness0.17 - 1.5mm
Width600 - 1250mm ( Usual : 914mm , 1219mm , 1220mm , 1250mm)
Surface TreatmentLaminate , Polished , Anodized
Useful Life:10 Years Indoor, 2 Years Outdoor Under Sunburn.
Base MaterialAluminum Sheet
Coil Weight1 - 3Tons
Delivery DetailsWithin 30 Days After Receive The Advance Payment
PackingStandard Seaworthy Export Packing : covering With Brown Paper And Plastic Film Then Packed With Wooden Case / Pallet



Specification :
■Standard : GB 2794 - 81 - 84
■Alloy : 1060 , 1085 , 3003 , 5052 , 8011 And Etc
■Thickness: 0.17 - 1.50 mm
■Width : 30 - 1500 mm ( Usual : 1000 mm , 1200 mm ,1250 mm)
■Surface Treatment : Laminate , Polished , Anodized
■Useful Life : 10 Years Indoor, 2 Years Outdoor Under Sunshine
■Surface Reflectivity Reach 86 % ,Diffuse Reflection Less Than 12 %
■Coil Weight : 1 - 3 tons
■Application of mirror aluminium sheet: Lighting, lamp, solar energy, Elevator, Nameplate, etc.

Anodized Mirror Aluminum Features :

Alloy

%

T.S

Rm / MPa

Y.S

Rp0.2 / MPa

Elongation

Total Reflectance

%

Diffuse Reflectance

%

IridescenceDescription
99.85130115286≤ 121Specular


This data sheet is as a guide only . Total reflectance is measured according to DIN5036 - 3 . Guage tolerance is within 1 / 2 of AA standard . Protective tapes are recommended for all items .

Iridescence classification
1 = low iridescence
2 = very low iridescence
3 = No Iridescence

Types of Mirror Aluminum :

No.TypeFeaturesAlloy / Temper
1LaminateStick a layer of high reflective vacuum zincification compound materials, strength of adhesive meets requirements of GB 2794 - 81 - 841060 & 3003 / H14 / H18 / H16 / H24
2PolishedSurface treatment by polished1060 & 3003 / H14 / H18 / H16 / H24
3Anodized1 - 4 micron oxidation film1085 / H14 / H18 / H16 / H24

Specifications Of Laminated Alu. Mirror Reflective Material Coil / Sheet
Reflectivity Rate> 83%
AlloyA1060
TemperH16 , H18
Thickness0.2 - 0.8mm
Width1000mm Or1250mm
Surface TreatmentLaminated
Shelf Life13 Years
LengthAs Required
Min Order Quantity1 Ton
FabricationCutting , Drilling , Punching , Bending , Etc
PackageStandard Seaworthy Export Package:wooden Pallets With Plastics Protection Or As Customer's Requirement


Applications :
I . Lighting : Such as grille lamp , lampshade , grille , diffuser of fluorescent lamp
II . Reflector plate of solar energy
III . Exterior of construction
IV . Interior decoration , such as aluminum buckle plate , ceiling , curtain wall
V . Elevator
VI . Nameplate ,
VII . The face panel of household appliance , microwave oven , refrigerator , etc.

Specular Laminate Aluminum Mirror Sheet For Reflector Plate Of Solar Energy
