Specifications
Brand Name :
HUIYI-GI
Model Number :
SPCC , SGCC , SGCH,SGCD , DX51/52/53/54D+Z , Q195/21
Certification :
SGS , BV , ISO9001
Place of Origin :
China
MOQ :
25tons each thickness
Price :
Negotiation
Payment Terms :
L/C, D/P, T/T
Supply Ability :
1000 tons per month
Delivery Time :
15-35days
Packaging Details :
Standard exporting package, wrapped with waterproof paper. Then high density PE film. after fully covered with iron sheet with metal edge protectors, strapped with metal bands
Product name :
GB/T 2518 DX51/52/53/54D+Z , Q195/21 Standard Galvanised Steel Coil Cold Rolled
Application :
Decoration , Flange Plate , Ship Plate, Building
Width :
under 1600mm
Thickness :
0.11-3.0mm
Zinc-coating :
Z20-Z600
Standard :
ASTM , AISI , GB , JIS , DIN
Shape :
coil/sheet/corrugated/flat
Coil ID :
508mm/610mm
Coil Weight :
According to customers' requirements
Description

GB/T 2518 DX51/52/53/54D+Z , Q195/21 Standard Galvanised Steel Coil Cold Rolled

It is made by taking hot galvanized sheet and zinc-iron alloy hot galvanized sheet as the substrate through surface pretreatment, coating one or more layers of liquid coating by roll coating, baking and cooling. The used coatings including polyester, silicon modified polyester, high-durability polyester, polyvinylidene fluoride, epoxy and high corrosion-resisting coating are widely used for building, transport, home appliances, solar energy, furniture, etc. It is mainly used as the side door plate of refrigerators, and shell of DVDs, air conditionings, freezers, and washing machines.Hot-dip aluzinc steel sheet is substrated on cold rolled steel(CRC)in various strength and specification Coating composition is 55%aIuminum in weight ratio.43 4%zinc.and 1 5%silicon with excellent corrosion and heat resistance performance.Hot-dip galvanized steel sheets (GI) are produced by passing the full hard sheet which has undergone the acid washing process and rolling process through the zinc pot, thereby applying zinc film to the surface. GI has a thicker galvanized layer which has excellent anti-corrosion qualities, and is the type of steel sheet used most commonly.

SPECIES GRADE STANDARD APPLICATION
PRESSING STEEL DX51D+Z, GB/T 2518 common use,deep drawing
DX51D+ZF
DX52D+Z,DX52D+ZF
DX53D+Z,DX53D+ZF
DX54D+Z,DX54D+ZF
S220GD+Z,S220GD+ZF
CONSTRUCTION STEEL S250GD+Z,S250GD+ZF GB/T 2518 construction material,corrosion resistance
S280GD+Z,S280GD+ZF
S320GD+Z,S320GD+ZF
S350GD+Z,S350GD+ZF
S400GD+Z,S400GD+ZF
S500GD+Z,S500GD+ZF
S550GD+Z,S550GD+ZF
HX260LAD+Z,HX260LAD+ZF
HX300LAD+Z,HX300LAD+ZF
HX340LAD+Z,HX340LAD+ZF
HX380LAD+Z,HX380LAD+ZF
HX420LAD+Z,HX420LAD+ZF
COLD ROLLED HIGH TENSILE STEEL HC260/450DPD+Z,HC260/450DPD+ZF GB/T 2518 including alloy steel,corrosion resistance,good pressing
HC300/500DPD+Z,HC300/500DPD+ZF
HC340/600DPD+Z,HC340/600DPD+ZF
HC450/780DPD+Z,HC450/780DPD+ZF

Q&A:

1. How to make sure your quality?

A: We have experienced inspector to check each order before production,if can not reach customer's quirements,we won't export to our clients.

2. Which contries does your company export to?

A: We have exported more than 20contries until now

Asia: Korea, Singapore, Vietnam, Thailand, Burma, India, Pakistan, Philippines,

Bangladesh, Nepal and Sri Lanka,Jordan, Israel, Saudi Arabia, Iraq, Iran,

Syria, Lebanon, UAE, Yemen

Europe: Romania, Turkey, Greece

Africa: Egypt, Algeria, Nigeria, Ghana, Sudan, Cameroon

Oceania: Australian
