Specifications
Brand Name :
Calin
Model Number :
Calinpay-S
Certification :
STS
Place of Origin :
China
MOQ :
Negotiation
Payment Terms :
Western Union, L/C, T/T, Paypal
Supply Ability :
7,000,000
Delivery Time :
30 days
Packaging Details :
With meters in carton or in memory card
Price :
Negotiation
Standard :
STS , IEC62055-51
O/S :
Windows
Database :
MICROSOFT ACCESS
Operation :
Multi-threaded transaction
Framework :
Standalone
Communication :
Internet, Intranet, LAN / WAN
Description

Prepayment Electricity Vending System commercial retail office parks different contractual tariffs

Commercial complexes such as retail and office parks may operate on a sectional basis where each section of the complex is owned by a different owner or they are owned by a single owner who tenen lets the sections of the complex to commercial tenants. The owners of the property or the section remains liable to settle utility bills or face penalties. Late or non-payment can increase costs and reduce profitability. As with residential body corporate scenarios, owners of commercial environments must also consider how they will collect revenues for the utilities consumed in the common or public spaces.

Similarly retail and office parks are normally metered by a bulk-meter where utility is supplied at a discounted tariff.

Calin's prepaid meters and prepayment vending system is availbe in both single and three phase configurations. Installed as sub-meter devices at the main distribution board located within each section or area, our prepaid meters can accurately meter and govern the utility supply to different shops or offices.

Our prepaid meters solution accommodate differences in contractual utility supply tarrifs between the owner and the tenants, enabling property owners or managers in commercial environments to align themselves with varying customer utility needs and contractual diffferences.

Prepayment  Electricity Vending System  commercial retail office parks different contractual tariffs

Key Benefit

1) Tenants prepay before being supplied with improve cash-flow

2) Zero cost for sectional meter reading service

3) Consumption on public complex spaces is covered by the different tariff rate between the bulk-supply and commercial supply

4) Flexible contractual settings

STS prepayment electricity meter Specification Datasheet

Parameter

1 Phase

3 Phase

Nominal voltage

110/120/220/230/240V

Un (40%- 130%)

3x110/120/220/230/240V Un(30%- 135%)

Norminal current

5(60)A

10(100)A

Connection type

Whole current / CTVT connection

Whole current / CTVT connection

Maximum current

80A

100A

Frequency

50Hz

50Hz

Accuracy class

IEC Class.1

IEC Class.1

Voltage circuit burden

≤1.5W & 1.2VA

≤1.5W & 5VA

Current circuit burden

≤0.2VA

≤0.5VA

Protective class

IP 54 as IEC 60529

IP54 as IEC 60529

Insulation class

6kV Class II

6.5kV Class II

Surge immunity

4 kV

4.3kV

Electrostatic discharge

15kV

16kV air discharge

Immunity to HF fields

80MHz to 2GHz@30V/m

80MHz to 2GHz@30V/m

Fast transient burst

4.3kV

4.3kV

Radio interference

As CISPR22

As CISPR22

Battery life without power

10 years

10 years

Dimension

160mmx112mmx71mm

290mmx170mmx85mm

Weight

Approximate 0.7kg

Approximate 3kg
