50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
Specifications
Applicable Industries :
Farms, Home Use, Other
Showroom Location :
United Kingdom, United States, Chile
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
Hot Product 2023
Warranty of core components :
1 years
Core Components :
Motor, Pressure vessel, Pump
Application :
Briquette Making Machine
Production Capacity :
150-220kg/h
Place of Origin :
China
Brand Name :
UT
Voltage :
380V/220V
Dimension(L*W*H) :
1.68*0.72*1.25
Weight :
700 KG
Features :
mechanical stamping type
Condition :
New
Warranty :
2 years
Raw Material :
Wood Sawdust
Product name :
Wood Biomass Briquette Making Machine
Keyword :
Straw Briquette Press Machine
Usage :
Rice Husk Briquette Maker
Name :
Sawdust Briquette Compression Machine
Finished Products :
Round Biomass Wood Briquettes
Suitable material :
Hard Wood Sawdust Rice Husk
Function :
Hydraulic Piston Press
Briquette shape :
Round Shap
Other name :
Shreddered Corrugated Board Briquette Making Machine
Price :
Negotiation
MOQ :
1
Packaging Details :
wooden box
motor :
220v/380v/415v/customzied
color :
customzied
key words :
briquette press machine
usage :
wood shavings, wood sawdust , shredded paper
Description
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
Product Overview

Home Use Small Business 50Mm 70Mm Biomass Sawdust Briquette Press Machine Shreddered Corrugated Board Briquette Making Machine

The biomass briquette plant is an eco friendly technology to convert diverse residues like forestry, industrial and agriculture waste into solid blocks of bio-fuel. Cylindrical shaped briquettes are made with high mechanical pressure using binder less technology. Hence no need for any binder or chemical.
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
Product Specifications
Briquette press machine is a pressing and forming machine for compressing forest residual into solid fuel briquette. Normally, there are 3 kinds of briquette machine in the market: Screw type briquette press machine, piston briquette press machine and hydraulic briquette press machine. Hydraulic briquette machine is equipped with hydraulic system which makes it different from ommon briquette machine.Due to the hydraulic device,the pressure for compressing raw materials can keep constant. In addition,when bigger or harder materials enter into rollers, the hydraulic system will work to project the roller and ensure higher efficiency
Model
UT-100
Capacity
100-150kg/h
Final product diameter
60mm
Power
7.5kw +2.5KW
Dimension
1200*1500*1320mm
Weight
700kg
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
Production Process
The whole charcoal production line mainly includes four needed machines: crusher, dryer, briquette making machine.
Raw Material → Crusher → Dryer → Briquette machine
1.Crusher
Crusher is to reduce the size of raw materials at 3-5mm, which is suitable for making the briquette. This crusher can crush: small tree branch, cotton stalks, tree bark, coconut shell, rice straw wheat straw, corn straw, grass river reeds, palm husk, soybean stalk or husk, coffee husk, paddy straw, sunflowers stalk, bamboo and many other agrowastes etc. And the whole production line can help you make the materials into the excellent wood fibers, flour and sawdust directly, save energy and high efficiency. So the invested cost of the charcoal making can be zero.
2.Dryer
Air current type dryer is to control the moisture content of raw materials at 8-12%, suitable for making briquette. Too dry or too wet will make the briquette loose, can’t have high density. It is professionally designed for drying different kinds of wood sawdust.
The whole system consists of fan blower, motor engine, fuel boiler, steel pipe, cyclone and air lock. In this sawdust dryer
machine system, wet material is input into hopper by screw feeder. Fuel furnace produces large volume of hot air. The hot air is driven into steel pipes, mixed with wet sawdust and moved through curving pipes and drying chamber by the power of fan blower. Fast moving hot air sustains and is mixed with raw material sent by spiral feeder in the suspending state through the steel pipe; moisture evaporates as the material traverses along the steel pipe and is rendered dry at the discharge end. Humid air is continuously exhausted, thus the material is dried.
3. Briquette making machine:
Briquetting is a process during which raw materials are compressed under high pressure and high temperature. After the processing of drying and pressing, the briquette is characterized by high density, small in size, better combustion, capable as the substitute for the superior coal or firewood.
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
Raw material
small tree branch, cotton stalks, tree bark, coconut shell, rice straw wheat straw, corn straw, grass river reeds, palm husk,
soybean stalk or husk, coffee husk, paddy straw, sunflowers stalk, bamboo and many other agrowastes etc
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
Final product
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
Other model for choose
we also supply the big capacity sawdust briquette machine this is our machine pictures, kindly check it.
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
Packing and shipping
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
Package
About Packing, for small size or single machine, we can offer free fumigation wooden case with steel frame, it not only can protect machine from damage, but also avoid checking when exporting.
For multiple machines or production line, it's better to loaded in standard container 20GP, 40GP, 40HQ, unually it needs wrapped with plasitc firstly, then loaded in container.

We can offer EXW, FOB and CIF terms.
EXW: You arrange the shipping details from our factory to your port by yourself.
FOB: We arrange freight transport to Qingdao, Shanghai or other ports of China, then you arrange the shipping details from China port to your country port.
CIF: We arrange all shipping details to your country port, and ensure machines smooth arrival.
50mm 70mm Biomass Sawdust Briquette Press Machine for Shreddered Corrugated Board
Our Service
Pre-sale:
1. Suggest to client suitable models of as customer need.
2. Introduce machine's structure and features in detail, explain the price component;
3. answer client concerned questions.
After-sale:
1. Start production as soon as receiving down payment.
2. Send photos of machine in manufacturing and finished photos to client, for your better learn about the machine's condition.
3. Delivery machine in time, taking photos during loading, so you can "remote monitoring" your goods.
4. Documents and certificate available in time.
5. Manual documents available. Engineer can be sent to client site for installation instruction.
