Flow Controller CAFS1000C Wide Flow Rate Range Of 0-60m/S, Strong Shock Resistance Of 100g. Output Mode: Analog Voltage Output (1 To 5V), Frequency Output (2.05-1.69KHZ), Two Options Available
Flow Controller CAFS1000C Wide Flow Rate Range Of 0-60m/S, Strong Shock Resistance Of 100g. Output Mode: Analog Voltage Output (1 To 5V), Frequency Output (2.05-1.69KHZ), Two Options Available
Flow Controller CAFS1000C Wide Flow Rate Range Of 0-60m/S, Strong Shock Resistance Of 100g. Output Mode: Analog Voltage Output (1 To 5V), Frequency Output (2.05-1.69KHZ), Two Options Available
Flow Controller CAFS1000C Wide Flow Rate Range Of 0-60m/S, Strong Shock Resistance Of 100g. Output Mode: Analog Voltage Output (1 To 5V), Frequency Output (2.05-1.69KHZ), Two Options Available
Specifications
Brand Name :
Consensic
Model Number :
CAFS1000C
Place of Origin :
CHINA
MOQ :
Please contact us for details
Price :
Offline conversation or face-to-face discussion
Payment Terms :
L/C/Ade/Pellet/Texi Union, MoneyGram, Alipay, and business-to-business payments
Supply Ability :
999
Delivery Time :
3-7 work days
Humidity Range :
0 to 100% RH
Calibration Method :
Air, 20°C, 101.325 kPa
Flow Range :
10-800 Kg/h (Customizable)
Response Time :
20 ms (Optional)
Description

Flow Controller CAFS1000C Wide Flow Rate Range Of 0-60m/S, Strong Shock Resistance Of 100g. Output Mode: Analog Voltage Output (1 To 5V), Frequency Output (2.05-1.69KHZ), Two Options Available

Overview:
The CAFS1000C Series MEMS Air Flow Sensor plays a vital role in modern automotive electronic control fuel injection (EFI) systems. It accurately measures the air intake in engine systems, providing the necessary data to optimize fuel injection, which directly impacts power, fuel efficiency, and emission control. Installed between the air filter and throttle body, it ensures the proper fuel-air mixture for optimal engine performance across varying conditions.
Key Features:
High Accuracy:
Feature: ±2.0% F.S accuracy.
Advantage: Ensures precise air flow measurements, critical for optimal fuel management in automotive systems.
Linear Output:
Feature: No temperature compensation needed.
Advantage: Delivers consistent and reliable output, simplifying system integration and reducing setup complexity.
Long-Term Stability:
Feature: Minimal zero drift over time.
Advantage: Guarantees reliable long-term performance, maintaining accuracy even after extended use.
Fast Response Time:
Feature: Responds in 20 ms.
Advantage: Provides real-time air flow data, supporting quick adjustments for dynamic driving conditions and engine performance.
Wide Flow Rate Range:
Feature: 0-60 m/s with strong impact resistance up to 100g.
Advantage: Capable of measuring varied flow rates, making it suitable for different vehicle types and engine configurations.
Solid-State Sensing Core:
Feature: No surface voids or fragile membranes, resistant to clogging and pressure shocks.
Advantage: Durable and maintenance-free, ensuring high performance in demanding automotive environments.
Flexible Output Options:
Feature: Analog voltage output (1 to 5V) and frequency output (2.05–11.69 KHz).
Advantage: Offers flexibility for integration into various systems, allowing easy adaptation for different applications.
High Reliability:
Feature: Suitable for relatively humid gas measurements.
Advantage: Performs reliably even in high-humidity environments, which is essential for automotive applications in diverse climates.
Wide Operating Temperature Range:
Feature: Operates from -40°C to 125°C.
Advantage: Ideal for automotive environments, withstanding extreme conditions and ensuring consistent operation in hot and cold climates.
Humidity and Condensation Resistance:
Feature: Operates effectively in 0 to 100% RH environments and is resistant to condensation.
Advantage: Ensures robust performance in high-humidity conditions, preventing sensor malfunctions due to condensation, which is common in automotive engines.

Performance Parameters

Functional Items CAFS1000C
Flow Range 10-800 Kg/h (Customizable)
Supply Voltage 14 VDC
Precision ±2.0 % F.S.
Repeatability <0.5 %
Response Time 20 ms (Optional)
Maximum Pressure 0.3 MPa
Output Modes Frequency output: 2.05~11.69 KHz, Analog output: 1-5 V (Optional)
Operating Temperature -40~125 °C
Storage Temperature -40~125 °C
Humidity Range 0 to 100% RH
Ingress Protection IP40
Calibration Method Air, 20°C, 101.325 kPa
Overall Material ABS
