CAFS3000 Linear Output And No Temperature Compensation Flow Meter
CAFS3000 Linear Output And No Temperature Compensation Flow Meter
Specifications
Brand Name :
Consensic
Model Number :
CAFS3000
Certification :
PTC22072602101C-CN01
Place of Origin :
WUXI
MOQ :
Please contact us for details
Price :
Offline conversation or face-to-face discussion
Payment Terms :
L/C/Ade/Pellet/Texi Union, MoneyGram, Alipay, and business-to-business payments
Supply Ability :
999
Delivery Time :
3-7 work days
Description

Key Features:

  1. High Accuracy: Achieves 1.5% Full Scale (F.S) accuracy for precise flow measurements.
  2. Linear Output without Temperature Compensation: Simplifies the system by providing linear output, but does not include temperature compensation.
  3. Long-Term Stability: Minimal zero-drift ensures sustained accuracy over extended periods.
  4. Robust Solid-State Sensing Core: No fragile surface cavity or film, making it resistant to blockages and pressure impacts.
  5. Versatile Output Options: Offers both analog (1-5 V) and digital (I2C) outputs.
  6. Quick Response Time: Extremely fast response time of 1 ms for dynamic flow changes.
  7. Wide Flow Range: Capable of measuring flow from 0 sccm to 2000 sccm.
  8. Adaptable to Humid Environments: Suitable for measuring gases in relatively humid conditions.

Maximum Ratings:

  • Operating Temperature: -25°C to 85°C
  • Storage Temperature: -40°C to 90°C
  • Humidity: 0-100% RH
  • Impact Resistance: Sensor can withstand up to 100 g impacts.
  • Condensate Resistance: Sensor can withstand water condensation.

Electrical Operating Characteristics:

  • Test Conditions: VIN = 12±0.01VDC, Ta = 25°C, Relative humidity: 40% < RH < 60%
  • Maximum Operating Temperature Range: -25°C to +85°C

Specifications:

Specification Minimum Typical Maximum Unit Remarks
Flow Range 0 — 3000 sccm Customizable
Service Voltage 8 12 24 V
Current — 20 15 mA
Maximum Voltage Output 4.94 5 5.02 V
Zero Point Voltage Output 0.98 1 1.02 V
Accuracy — 1.5 2 %FS
Withstand Voltage — 0.3 — MPa Customizable
Resolution Ratio — 0.1 — % Full scale
Response Time — 20 30 ms
Zero Drift — 0.2 — %Year Full scale
Temperature Drift — — 4 % 0°C to 50°C
Overall Material Silicon carbide, epoxy resin, PS, FR 4, silicon as sealing material
