CPG Full Range Output 10kPa MEMS Based Pressure Sensor
CPG Full Range Output 10kPa MEMS Based Pressure Sensor
CPG Full Range Output 10kPa MEMS Based Pressure Sensor
CPG Full Range Output 10kPa MEMS Based Pressure Sensor
Specifications
Brand Name :
Consensic
Model Number :
CPG
Place of Origin :
WUXI
MOQ :
Please contact us for details
Price :
Offline contact or face-to-face discussion can be negotiated
Payment Terms :
L/C/Ade/Pellet/Texi Union, MoneyGram, Alipay, and business-to-business payments
Supply Ability :
999
Delivery Time :
3-7 work days
resistance temperature coefficie-nt :
1500~2500ppm /℃
Measuring Range :
-100 kPa to 700 kPaVarious ranges available
Zero-point output temperature coefficient, TCO :
-0.08~0.08%FS /℃Constant pressure mode/Constant flow mode
Arm Resistance :
4.5~5.5kΩ
Description

Features

  • Measuring Range: -100 kPa to 700 kPa (Gauge and negative pressure measurement)
  • High Sensitivity, Stability, and Reliability: Excellent for precise and consistent pressure measurements.
  • Driving Modes: Supports constant voltage source or constant current source drive.
  • Measurement Types: Capable of gauge (relative to atmospheric pressure) and negative pressure measurements.
  • Back Cavity Pressurization: Designed for measuring dry and non-corrosive gases.
  • Customizable Pin Definition: Pin configurations can be tailored to customer requirements.
  • Small Size, Low Cost: Compact and affordable design for cost-effective applications.

Product Description

The CPG Series pressure sensor is an all-silicon MEMS pressure sensor designed to provide accurate pressure measurements across a wide range of pressures from -100 kPa to 700 kPa. It is built to deliver high sensitivity, excellent stability, and long-term reliability, making it suitable for a diverse array of applications.

This sensor operates over a broad temperature range of -40°C to 125°C and is available in both standard SOP and DIP packages, which makes it easy to integrate into various systems. The sensor provides a high-quality linear output voltage that correlates well with pressure changes, and it supports both constant voltage and constant current source drive modes, offering flexibility for different design requirements.

Applications include:

  • Automotive Electronics: TPMS (Tire Pressure Monitoring Systems), MAP (Manifold Absolute Pressure) sensors, oil pressure testing.
  • Household Electronics: Rice cookers, soybean milk machines, water purifiers, coffee machines, massagers, massage chairs, air cushion beds.
  • Industrial Control: Air compressors, pumps, fire fighting equipment, diving gear, dam monitoring.
  • Medical Monitoring: Oxygen equipment, electronic sphygmomanometers, massagers, medical monitors, nebulizers.
  • Others: Vacuum packaging machines, vacuum mixers, vacuum wall breakers, vacuum fresh-keeping boxes, vacuum pumps, and other vacuum/negative pressure applications.

Product Performance Parameters

Parameter Smallest Typical Maximum Unit Remark
Supply Voltage - 5 10 Vdc
Supply Current - 1 - mAdc
Pressure Range 10, 40, 100, 700 - - kPa Various ranges available
Arm Resistance 4.5 5 5.5 kΩ
Zero Bias -15 0 +15 mV
Full-Scale Output (for various ranges) 18 to 120 - - mV Varies with range
Nonlinearity - 0.2 0.5 %FS
Zero Output Temperature Coefficient (TCO) -0.08 -0.03 0.08 %FS/°C Constant voltage mode
Full-Scale Output Temperature Coefficient (TCS) -0.27 -0.22 -0.17 %FS/°C Constant voltage mode
-0.05 ±0.02 0.05 %FS/°C Constant current mode
Temperature Coefficient of Resistance 1500 2000 2500 ppm/°C
Stability - 0.2 - %FS/Y
Pressure Hysteresis - 0.05 0.1 %FS
Overload Pressure 3× - - -
Operating Temperature -40 - 125 °C
Storage Temperature -40 - 150 °C
