Specifications
Warranty :
1 year
Customized support :
OEM, ODM
Place of Origin :
Shandong, China
Brand Name :
WYYW
Model Number :
Y-40Z
Material :
black steel case brass internals
Original place :
Made in china
Dial Size :
40mm
Pressure Range :
Made as requirments, Mpa, bar, psi, kg etc.
Oil filled :
No oil/ Dry
Producing experience :
10 years
Certification :
CE,ISO
Packaging Details :
black steel portable pressure gauge
Each unit is packed in one paper box, 30 box in one carton . As customer requested.
Port :
QingDao,ShangHai,Ningbo,Guangzhou
Supply Ability :
100000 Piece/Pieces per Month black steel portable pressure gauge
MOQ :
1000 pieces
Price :
$1.30/pieces 1000-4999 pieces
Description

black steel portable pressure gaugecommon Y-40Z0-10BAR PSI 40mm 1.5

Product Description

common Y-40Z0-10BAR PSI 40mm 1.5

Name

Standard Industrial pressure gauge

Dials Size

40/50/60/75/100/150/200mm (or dail size made as demand)

Case

Black steel case

Pressure

Mpa,other scale units bar, psi, kg/cm2 etc.optional

Ring

None

Movement

Brass

Socket

Brass

Bourdon tube

Phosphor Bronze

Dial plate and pointer

Aluminum

Window

Glass

Connection sizes

1/8" for 1.5", 1/4 for 2",2.5" case; 1/2 for 4",6"

Connection threads

Metric Thread, NPT, BSP (G, PF), BSPT (ZG, PT)

Mounting

Back (Or made as panle, bottom)

Accuracy

1.5"(40mm), 2"(50mm), 2.5(63mm)-2.5%
4(100mm) and 6 (150mm)-1.6%

Pressure limitation

Steady: 3/4x full scale value
Fluctuation:2/3x full sacle value
Short time:full scale value

common Y-40Z0-10BAR PSI 40mm 1.5

common Y-40Z0-10BAR PSI 40mm 1.5

common Y-40Z0-10BAR PSI 40mm 1.5

Product Application

1.Outdoor and severe ambient and process conditions

2.Use where harmful vibration and pulsation are present

3.Hydraulic equipment, pressure washers,oil field equipment, pumps, compressors and process systems

common Y-40Z0-10BAR PSI 40mm 1.5

Company Information

Qingdao DaZeFengYang is one professional pressure gauge and hardware tools manufacturer, who is also one member of China National Hardware Association.

Together with our highly skilled technical experts, we have put an effort to meet the quality of pressure gauge as per GB/T (Chinese Standard) & International Standards requirements, and have already got ISO9001, CE certificate for all our products, including:
pressure gauge, gas regulator, cutting torch and welding torch etc.

Over the passed years development, there is now an impressive selection of products, both special and standard, with keen prices and deliveries, which together with the speedy sales and after sales service make our company attractive to customers all around the world, especially for those distributors and importers from Europe, Southeast Asia,Middle East, America and Australia.

Welcome every friend to call, email us and visit our company. We sincerely hope to create wonderful future together with you.

common Y-40Z0-10BAR PSI 40mm 1.5

common Y-40Z0-10BAR PSI 40mm 1.5

common Y-40Z0-10BAR PSI 40mm 1.5

Packaging & Shipping

common Y-40Z0-10BAR PSI 40mm 1.5

Advantages

1.Advance Equipment and Professional Technology : we are committed to offer the good quality gauges with advance equipment and professional technology for all over the world customers.

2.Best After-sales Service:Our company provide best after-sale service all the time , for our goal is a long trade cooperation term;

3.Serious Inspection Procedure with Excellent Quality: Our pressure gauges all are 100% inspection , we also have passed ISO9001 and UL certificated;

4.Quickly Delivery: Our company provides in-time delivery with , always satisfy customers needs;

5.Convenient Purchase and save cost: We are skillful manufacturer, so it's convenient for you to purchase , We can provide our high quality products with reasonable price;

6.OEM orders: In the past years, we have many OEM orders from very famous company in USA and European market .
