Specifications
Place of Origin :
Shandong, China
Brand Name :
WYYW
Model Number :
YX-100
Certification :
CE,ISO
Packaging Details :
100mm Stainless Steel Electrical Contact Pressure Gauge
Each unit is packed in one paper box, 30 box in one carton . As customer requested.
Supply Ability :
100000 Piece/Pieces per Month 100mm Stainless Steel Electrical Contact Pressure Gauge
MOQ :
100 pieces
Price :
$28.00/pieces 100-499 pieces
Warranty :
1 year
Customized support :
OEM, ODM
Size :
100mm
Payment :
various payment methods
Material :
stainless steel
Keyword :
pressure gauge
Type :
Electric contact
Oil filled :
Yes
Connection :
1/2"BSP
Port :
Qingdao
Description

100mm Stainless Steel Electrical Contact Pressure Gauge

0-1MPa Electrical Contact Pressure Gauge , Silicone Oil Filled Pressure Gauge With Flange

Product Description

0-1MPa Electrical Contact Pressure Gauge , Silicone Oil Filled Pressure Gauge With Flange

Name

pressure gauge

Dials Size

1.5"(40mm), 2"(50mm), 2.5“(63mm), 4”(100mm) and 6“ (150mm)

Case

Black steel, ABS or chrome plated

Pressure range

0 -250Mpa,other scale units bar, psi, kg/cm2 etc.optional

Movement

SS304 and 316

Socket

BSS304 and 316

Bourdon tube

SS304 and 316

Dial plate and pointer

Aluminum

Window

Glass or Plastic

Connection sizes

1/8 for 1.5" case; 1/4 for 2",2.5" case, 3/8"&1/2" for 4",6"case

Connection threads

NPT, BSP (G, PF), BSPT (ZG, PT)

Mounting

Bottom,back and panel

Accuracy

1.5"(40mm), 2"(50mm), 2.5(63mm)-2.5%
4(100mm) and 6 (150mm)-1.6%

Pressure limitation

Steady: 3/4x full scale value
Fluctuation:2/3x full sacle value
Short time:full scale value

0-1MPa Electrical Contact Pressure Gauge , Silicone Oil Filled Pressure Gauge With Flange

0-1MPa Electrical Contact Pressure Gauge , Silicone Oil Filled Pressure Gauge With Flange

0-1MPa Electrical Contact Pressure Gauge , Silicone Oil Filled Pressure Gauge With Flange

Product Application

1.Outdoor and severe ambient and process conditions

2.Use where harmful vibration and pulsation are present

3.Hydraulic equipment, pressure washers,oil field equipment, pumps, compressors and process systems

0-1MPa Electrical Contact Pressure Gauge , Silicone Oil Filled Pressure Gauge With Flange

Company Information

Qingdao DaZeFengYang is one professional pressure gauge and hardware tools manufacturer, who is also one member of China National Hardware Association.

Together with our highly skilled technical experts, we have put an effort to meet the quality of pressure gauge as per GB/T (Chinese Standard) & International Standards requirements, and have already got ISO9001, CE certificate for all our products, including:
pressure gauge, gas regulator, cutting torch and welding torch etc.

Over the passed years development, there is now an impressive selection of products, both special and standard, with keen prices and deliveries, which together with the speedy sales and after sales service make our company attractive to customers all around the world, especially for those distributors and importers from Europe, Southeast Asia,Middle East, America and Australia.

Welcome every friend to call, email us and visit our company. We sincerely hope to create wonderful future together with you.

0-1MPa Electrical Contact Pressure Gauge , Silicone Oil Filled Pressure Gauge With Flange

0-1MPa Electrical Contact Pressure Gauge , Silicone Oil Filled Pressure Gauge With Flange

0-1MPa Electrical Contact Pressure Gauge , Silicone Oil Filled Pressure Gauge With Flange

Packaging & Shipping

0-1MPa Electrical Contact Pressure Gauge , Silicone Oil Filled Pressure Gauge With Flange

Advantages

1.Advance Equipment and Professional Technology : we are committed to offer the good quality gauges with advance equipment and professional technology for all over the world customers.

2.Best After-sales Service:Our company provide best after-sale service all the time , for our goal is a long trade cooperation term;

3.Serious Inspection Procedure with Excellent Quality: Our pressure gauges all are 100% inspection , we also have passed ISO9001 and UL certificated;

4.Quickly Delivery: Our company provides in-time delivery with , always satisfy customers needs;

5.Convenient Purchase and save cost: We are skillful manufacturer, so it's convenient for you to purchase , We can provide our high quality products with reasonable price;

6.OEM orders: In the past years, we have many OEM orders from very famous company in USA and European market .
