Specifications
Brand Name :
ACMESENSOR
Model Number :
APT260
Certification :
CE
Place of Origin :
China
MOQ :
1pieces
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Packaging Details :
APT260 Differential Pressure Transmitter price: standard exporting package
Range:: :
-1-0-1 bar...1000 bar optional
Highest Accuracy:: :
0.25%F.S
pressure interface:: :
M20x1.5, G1/4,G1/2,1/4NPT, 1/2NPT
Output signal:: :
4~20mA,0~5V/0~10V/0.5~4.5V,Relay Signal
Power supply:: :
12~36Vdc/7-30V
Working Temp:: :
-25℃~85℃
Pressure type:: :
gauge pressure,sealed gauge pressure
Electronic connection:: :
DIN43650 Hirschman connector
Warranty:: :
16 Months
Customized:: :
Accpetable
Description

Hot selling electronic water pump auto switch pressure with low price/adjustable pressure switch for water pump

Feautures:

- Programmable automatic control design
- OLED with back-light display
- Display 180°turnable
- Displaying pressure peak value and environment temperature
- Body 330°rotable
- Industrial touch-sensitive button
- Switch points settable
- PNP/NPN +4~20mA/0-5V output
- Support MODBUS
- Pressure, level and temperature switch
- OEM & Customizable

Electronic Water Pump Auto Switch Adjustable Pressure Switch For Water Pump

Characters:
Applications:
♦Accuracy:≤±0.5%FS
♦ Sanitary field of food,drink and milk
♦ Wide working temperature scope
♦ Milk Plant/factory
♦ Advanced digital temperature compensation
♦ soft drink factory
♦ Excellent resistance against impact,overload,
♦ drink water factory
♦ shock and erosion
♦ Sea water level measurement and control
♦ Highly-efficient lighting adsorption and strong
♦ Juice level measurement
♦ RFI & EMI resistance
♦ Oil and fuel tank level measuring
♦ Impact resistance and disturbance
♦ Automatic detection system
♦ 1.5 times range standard overload
♦ Saving water to irrigate
♦ 3 times range burst pressure
♦ Tank pressure and level measurement
♦ CE approving
♦ And so on

Characteristic:

Characteristic of APT260 Series Pressure Sensor
1
Germany technology Ceramic sensors, 10 years design
2
Ti special integrated processing chip is used in the circuit
3
Automatic temperature compensation -40~80
4
Superior Long term Stability,low temperature drift, high sensitivity
5
Multiple electrical connection are optional ,easy installation
7
Wide range,available to Gauge,Absolute and sealed gauge type
8
HVAC Systems ·Energy and Water Treatment
9
EMI/RFI Rejection

Size information:

Electronic Water Pump Auto Switch Adjustable Pressure Switch For Water Pump

Specification:

Ambient Temperature: 25°C (unless specified)

Pressure Range

0 ... 0.07 to 0 ... 1000bar

Pressure type

pressure

Overload pressure

1.5times rated pressure

Accurancy

F.S±0.25% F.S, ±0.5% F.S

Stability

Typical values:0.1% FS; Max values:0.2% FS

Operating temperature

-40°C~85°C

Output singal

4~20mA 0~5V 0~10V

Power supply

10~36Vdc

Electrical connection

Waterproof lead with fixed cover , protection rank: IP68;

Connector; DIN43650, shell protection: IP65

Lightning proof

Air-conduction pressure : 8000V,

Shell & cable conduction pressure: 4000V

Certification

Intrinsic safety certification Explosion certification, CE certification

Applications case:

Electronic Water Pump Auto Switch Adjustable Pressure Switch For Water Pump

Packaging and Transportation:

Electronic Water Pump Auto Switch Adjustable Pressure Switch For Water Pump

FAQ

Q:What kind of products do you offer ?

A:We supply pressure sensor, level sensor, flow meter and digital controllers. Main market is European countries, American, the Middle East and Asia. Certificates are international ones.


Q:Could I get samples?
A:Yes,we have materials in stock to help you to get the samples as soon as we can.


Q:How about the quality of the magnets?
A:We have the certification of ISO, Europe standard ATEX, TUV-CE and ROSH,we could send the certification test of our company to you.


Q:Could you provide me the shortest lead time?
A:We have materials in our stock,if you really need,you can tell us and we will try our best to satisfy you.


Q:Could I visit your factory?
A:Of course,if you need we will help you to visit our factory.


Q: How can I get the quotation or send my inquiry to?
A: Send your inquiry to us by the inquiry from on the right-side or the bottom of this page.
