Gas Oil Ceramic Capacitive Pressure Sensor
Gas Oil Ceramic Capacitive Pressure Sensor
Gas Oil Ceramic Capacitive Pressure Sensor
Gas Oil Ceramic Capacitive Pressure Sensor
Gas Oil Ceramic Capacitive Pressure Sensor
Gas Oil Ceramic Capacitive Pressure Sensor
Specifications
Place of Origin :
China
Brand Name :
OEM
Supply Ability :
20,000 pcs per month
Packaging Details :
Stardard Export Packing By carton
MOQ :
Negotiable
Price :
Negotiable
Output :
0.5-4.5VDC
Accuracy :
0.5%FS 1%FS
Pressure range :
10 16 25 bar
Output signal :
0.5-4.5VDC
electrical connection :
Packard connector
screw :
G1/4, 1/8NPT
product electrical connection :
Hirschmann, Packard
Product Name :
CE 0 10 bar Hydraulic Gas Oil Ceramic Capacitive Pressure Sensor
Certification :
CE;ISO
Delivery Time :
5-10days
Payment Terms :
L/C, T/T, Western Union
Description

Gas Oil Ceramic Capacitive Pressure Sensor

Product Description
Product Induction
Low Cost 0-10 bar Hydraulic Gas Oil Ceramic Capacitive Pressure Sensor adopts ceramic materials by a special refined process. The ceramic materials with high elasticity, corrosion resistance, abrasion resistance, shock and vibration characteristics and good thermal stability characteristics. The sensor with high accuracy, overload capacity, high output, wide range of features, widely used in automobiles, home appliances, air compressors, refrigerators and other equipment.
Features
♦ High accuracy, good stability
♦ Excellent corrosion resistance, abrasion resistance, vibration resistance
♦ Sturdy and compact construction
♦ Wide temperature range, small size
Applicable Scope
♦ car
♦ Appliances
♦ Air compressor, refrigerator
♦ Industrial process detection and control
Standard Range
Pressure type: gauge pressure
Pressure range (bar) : 10 16 25 bar
Technical Index
Signal output 0.5-4.5VDC
Power supply 5VDC
Accuracy 0.5%FS, 1%FS
Working Temperature -20~+125°C
Storage Temperature -40~+105°C
Overload Pressure 200% FS
Burst Pressure 300% FS
Impact (11ms) 100g
IP Grade IP65
Material Stainless steel 304
Electrical connection Packard connector with 1m cable
Pressure Port G1/4 NPT1/8

Gas Oil Ceramic Capacitive Pressure SensorGas Oil Ceramic Capacitive Pressure Sensor

Our Services

1, Price : EXW, FOBChangsha
2, Payment: 100% T/T in advance .
3, Packing : standard export packing , including instructions and certificate
4, Leading time : 7-10 working days.
5, OEM avaliable
6, Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder
7. 7 days free replace & 1 year free repair for quality warranty
