Specifications
Brand Name :
WITGAIN PCB
Model Number :
S04E4676A0
Certification :
UL Certificate
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
1kkpcs/month
Delivery Time :
25 work days
Packaging Details :
1080pcs/bag, 20bags/carton
Via Hole :
L1-L4 0.15MM
Blind Hole :
L1-L2 0.15MM, L2-L3 0.15MM
Material :
FR4
Layer Count :
4 Layer
Surface Treatment :
ENIG
Solder Mask :
Green
Copper Thickness :
1/1/1/1OZ
Unit Size :
97.5mm*91.2mm/54up
Description

4 Layer Printed Circuit Board With Blind And Buried Holes

PCB Specifications:

Layer Count: 4Layer HDI PCB

Board Thickness: 0.8MM

Material: FR4

Copper Thickness: 1/1/1/1OZ

Min Hole: 0.1MM

Min Line: 3.5/3.5 Mil

BGA Size: 7.9Mil

Unit Size: 97.5*91.2MM/54UP

Hole: L1-L4, L1-L2, L1-L3

Solder Mask: Green

Silkscreen: White

Surface Treatment: ENIG

Capabilities:

Item Capability
Layer Count 1-24 Layers
Board Thickness 0.1mm-6.0mm
Finished Board Max Size 700mm* 800mm
Finished Board Thickness Tolerance +/-10% +/-0.1(<1.0mm)
Warp <0.7%
Major CCL Brand KB/NanYa/LTEQ/ShengYi/Rogers Etc
Material Type FR4,CEM-1,CEM-3,Aluminum,Copper,Ceramic, PI, PET
Drill Hole Diameter 0.1mm-6.5mm
Out Layer Copper Thickness 1/20Z-8OZ ;
Inner Layer Copper Thickness 1/3OZ-6OZ
Aspect Ratio 10:1
PTH Hole Tolerance +/-3mil
NPTH Hole Tolerance +/-1mil
Copper Thickness Of PTH Wall >10mil(25um)
Line Width And Space 2/2mil
Min Solder Mask Bridge 2.5mil
Solder Mask Alignment Tolerance +/-2mil
Dimension Tolerance +/-4mil
Max Gold Thickness 200u'(0.2mil)
Thermal Shock 288C, 10s, 3 Times
Impedance Contro +/-10%
LTest Capability PAD Size Min 0.1mm
Min BGA 7mil
Surface Treatment OSP, ENIG, HASL, Plating Gold, Carbon Oil,Peelable


FAQ:

Question: What is DRC in Printed Circuit Boards?

Answer: Design Rule Checking (DRC) is a process used to identify errors and mismatches such as spacing & trace widths in a PCB design/layout. The layout of a PCB board is designed using software, each PCB fabricator has a set of rules which they publish that specify various parameters such as what the spacing between each line should be, the minimum size of vias, the width of a line etc.

0.1MM Hole 7.9Mil BGA 0.8MM FR4 4 Layer HDI PCB Board

Once a design is submitted to a PCB Fabricator, they run a DRC to ensure that the submitted design complies to their published standard. This ensures that the PCB will be fabricated to spec. If there are any mis-matches the DRC points them out and the designer then updates the design/layout accordingly. DRC (Design Rule Checking) is a must to ensure there are no design violations in the PCB. This check is done prior to the manufacturing of the final board.

The Design Rules are different for each PCB fabricator. Users should check the design rules of a PCB fabricator before submitting a PCB Design to the manufacturer.
