Specifications
Brand Name :
HONGYU
Model Number :
HY-2030ZP4A
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
30 set
Delivery Time :
5-8 work day
Packaging Details :
wooden case
color :
singel color
condition :
new
warranty :
1 year
usage :
label printer
type :
screen printer
weight :
200kg
dimension :
1000*1000*1500mm
automatic grade :
semi automatic
Description
40W 4 Stations Flat Screen Printing Machine flatbed screen printer With Robot Arm
4 Stations Flatbed Rotary Screen Printing Machine printer with Robot Arm
The flatbed screen printer is design for high effeciency, with Taiwan TANTZU cam indexer for worktable running.
you can put in and take out objects at the same time, high printing capacity, 2/4/8 workstation is optional.
speed can up 2800 times/hour. suitable for print any flat products, like plastic/metal shell,lighter,small gift box,nameplates
etc.
Specification
Advantage
1. Adopt Taiwan TANTZU cam indexer ruuning, accurate location.
2. Taiwai motor driven the conveyor, fast and stable printing.
3. PLC with man-machine touch screen, programmable printing process.
4. Screen frame can be adjusted by left/right, front/back, up/down or level orientation.
5. Scraper constant pressure device to ensure the stability of the pressure.
6. Equipped with CEC shock absorber, precise and stable printing for multi-color.
7. Emergency switch, safe return system and automatic debug warning, safety protection.
8. Auto unloading with mechanical robot arm, high effeciency.
Model No
HY-2030RT4A
Worktable size
Φ600mm
Max. printing area
200*300mm
Max frame size
300*500mm
Printing speed
2800 times/hr
Max height of work piece
60mm
Transverse stroke
400mm
Vertical stroke
100mm
Air pressure
5~7bar
Voltage
110V/220V 50/60 HZ40W
Machine size
1000*1000*1500mm
