Specifications
Brand Name :
Gaoxin
Model Number :
GX-5055
Place of Origin :
China
MOQ :
1set
Price :
negotiation
Payment Terms :
FOB Shenzhen, T/T
Supply Ability :
50 sets per month
Delivery Time :
15 working days
Packaging Details :
Non-fumigation wooden box
Sample grip area :
100cm2
Hydrostatic pressure rate :
60mbar/min
Measuring scale :
0～100kpa, 0~200kpa
Test accuracy :
±0.2%, ±0.5%
Dimensions :
W580 × D400 × H700mm
Weight :
75kg
Description

Textile Hydrostatic Pressure Testing Machine Color Fastness To Washing Tester

Application: This machine is used to test the water resistance of products to water penetration. It is suitable for tight fabrics, such as canvas, linoleum, tent cloth, tarpaulin, non-woven fabrics and rainproof clothing fabrics, coated fabrics, composite materials, etc.

Test Standards: JIS-L1092,GB/T4744,FZ/T01004,ISO811,AATCC127,GB19082-2008,YY/T1498-2016

Feature:

1.This instrument is controlled by an industrial 32-bit microprocessor and has five test functions

  • Pressurization

  • Constant pressure timing

  • Constant pressure and time

  • Flexing relaxation method

  • Water leakage method

2. With Colorful touch screen, simple and convenient operation

3. High-precision pressure sensors with accurate and stable test results and good repeatability

4. With a built-in water tank, Water shortage protection.

5.The water pressure rising rate can be adjusted steplessly, and it has the functions of effective button prompts and fault self-tests.

6. One button control water-adding and water-discharge

7. High brightness LED lighting

8. Built-in compact printer, able to print test report directly.

Technical parameter:

Model # GX-5050-C10 GX-5050-C20
Measuring scale 0～100kpa 0～200kpa
Test accuracy ±0.2% ±0.5%
Sample grip area 100cm2
Test units Pa, KPa, mmH2O, cmH2O, mbar
Hydrostatic pressure rate 60mbar/min (0.1Kpa~100Kpa adjustable)
Water tank capacity 2500ml
Dimensions W580 × D400 × H700mm
Weight 75kg
Power AC220V, 50Hz or according to specific voltage (such as AC110V)
