Specifications
Brand Name :
Gaoxin
Model Number :
GX-3000-L
Certification :
ISO 2008
Place of Origin :
China
MOQ :
1set
Price :
negotiation
Payment Terms :
FOB Shenzhen, L/C, T/T, Western Union
Supply Ability :
50 sets per month
Delivery Time :
15 working days
Packaging Details :
Non-fumigation wooden box
material :
304# stainless steel
color :
silver
displayer :
Touch screen
test standard :
IEC 68-2-6（FC), GB2423, JJG189-97, GB/T13309-91
controller :
programmable controller
usage :
high termperature, low temperature, and humidity resistance test
applicable object :
optical fiber, LCD, battery, computer, mobile
spraying method :
Continuous spray or intermittent spray
Description

Customised Lab Equipment Walk In Environmental Chamber Temperature And Humidity Fast Change Test Chamber

Quick Details

Alternative name

Programmable temperature and humidity testing machine

Function

Test high and low temperature, moisture resistance of various

products

Type

Programmable controlling system and touch screen display

Weight

Customer specified

Internal space

Customer specified

Corresponding test standard

IEC 68-2-6(FC), GB2423, JJG189-97, GB/T13309-91

Equipment summary:

The environmental condition test machine is consist of Control Panel, electrical panels, moisturizing plate blower, heater, humidifier, freezer. It provides a large spare to test the temperature and humidity for large-scale parts, semi-finished products, it applied to test products that large-scale or the quantity more, such as: Computer terminals, vehicle parts.

Corresponding standard:

1. GB11158 Technical conditions for high-temperature testing room
2. GB10589-89 Technical conditions for low-temperature testing room
3. GB/T10586-89 technical conditions for humidity testing room
4. GB/T2423.1-2001 testing methods for low-temperature
5. GB/T2423.2-2001 testing methods for high-temperature
6. GB/T2423.3-93 technical conditions for humidity testing room
7. GB/T2423.4-93 testing method for alternating hot and humid
8. IEC60068-2-1.1990 testing methods for low-temperature
9. IEC60068-2-2.1974 testing methods for high-temperature
10. GJB150.3 High-temperature test
11. GJB150.4 Low-temperature test
12. GJB150.9 muggy test
13. GB/T2423.22 temperature test

Applicable Industry

The environmental condition test machine was used in defense industry, aerospace industry, automation components, automotive parts, electrical and electronic parts, plastics, chemical, pharmaceutical industries and related products

Features of environmental condition test machine:

1, large walk-in constant humidity and temperature testing machine has a very wide range of controlling the temperature and humidity that can fulfil users needs. It is stable, balanced heating and humidification performance, it also can be high accuracy and high stability for temperature and humidity control performance,
2, walk-in constant humidity and temperature testing machine is equipped with high-precision intelligent thermostat, controller of temperature and humidity using touch-screen display. Optional equiped with temperature and humidity records
3, Refrigeration circuit of large walk-in constant humidity and temperature testing machine automatically select to operate performance of refrigeration circuits, so that it starts cooling at high-temperature state.
4, Door of large walk-in constant temperature and humidity testing machine with large viewing window for observation of the testing sample.
5, large walk-in constant humidity and temperature testing machine is equipped with advanced security, protective device leak circuit breakers, over-temperature protective device, lack phase protective devices and lack water protector.
Technical Parameter
Madol GX-3000-L Walk in environmental condition test machine
Size (cm) According to customer specified size for design
Temprature range -65 degree ~+80 degree( A:0 degree, B:-20 degree, C:-40 degree, D:-65 degree );
capacity (low-temperature:A~D) option
Humidity range 20%~95%R.H.
Accuracy/uniformity ±0.1 degree, ±0.1%R.H. / ±1.5 degree,±5.0%R.H.
Accuracy/volatility ±1.0 degree, ±2.0%R.H./±0.5 degree, ±3.0%R.H.
Cooling time About 4.0/minute
Inside material stainless steel
Insulation material High-temperature high-density amino acid ethyl ester foam insulation materials,
Cooling sytem Water-cooled / two-stage compressor
Protection No fuse switch, compressor overload switch, high and low pressure protective switch, over-humidity-temperature protective switches, fuses, warning system
accessories recorder(option), view window, 50mm testing hole, PL lamp, clapboard, Dry and wet gauze ball
controller Korea TEMI or Japan OYO brand option
compressor France's Tecumseh Brand

power

 1Φ 220VAC±10% 50/60Hz & 3Φ 380VAC±10% 50/60Hz
