Transparent 19 Inch Tft Capacitive Touchscreen , Waterproof Touch Screen Panel,Walll Mount Table Financial System
Transparent 19 Inch Tft Capacitive Touchscreen , Waterproof Touch Screen Panel,Walll Mount Table Financial System
Transparent 19 Inch Tft Capacitive Touchscreen , Waterproof Touch Screen Panel,Walll Mount Table Financial System
Transparent 19 Inch Tft Capacitive Touchscreen , Waterproof Touch Screen Panel,Walll Mount Table Financial System
Specifications
Brand Name :
Touch China
Model Number :
ZCC-4616
Certification :
CE,ROHS
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
2K per month
Delivery Time :
20 working days
Packaging Details :
Standard export package
Type :
Projected capacitve touch screen
Size :
19 inch
Touch points :
10
Aspect Ratio :
16:9
Structure :
G+G
Surface Hardness :
≧6H
IC solution :
ILITEK
Application :
Kiosk Touch Screen
Description

Kiosk flexible transparent 19 inch Touch Panel

for TFT LCD module

Basic specification:

Size 19 inch
Total thickness 2.4±0.3mm
Outline of Cover Lens 421*346±0.3mm
Outline of ITO Sensor 393.62*320.34±0.3mm
Viewing Area 377.32*302.06±0.3mm
Active Area 380.32*305.06±0.3mm
Interface USB
Input voltage DC5V
Response time 10ms
Panel color Black
Transmittance ≧85%
Input method Hand writing or capacitive pen
Package list 19 inch touch panel,controller board and USB cable

Features:

1. Projected Capacitive touch screen
2. Customization
3. 3.5 inch to 65 inch(More large sizes products are developed now)
4. Multi touch point
5. OS support:Windows 7/8/10,Android,Linux,XP,WCE
6. USB/IIC port

7. Low MOQ

Applications:

Kiosk,Karaoke,All in one,Digital Signage,Tablet pc,Advertising player,
Education Whiteboard,Medical device,Industrial pc panel,Multi-touch table,

POS,Restaurant menu,ATM etc.

Competitive advantages:

1. We have 23-year experience in designing and manufacturing touch panels.

2. We have strong research team for both software and hardware and provide before and after-sale service.

3. We cooperate with excellent customers and suppliers.

4. We have long-term cooperation with excellent IC suppliers all over the world.

5. We have good guarantee for product quality and lead time.

6. Our touch panels of large sizes and touch panels for automobile are in a leading position in touch panel industry.

Delivery time:

Sample: 10-15 working days

Mass production:

1.Small sizes(smaller than 12.1 inch): 18 working days.

2.Large sizes(larger than 12.1 inch):20-25 working days.

Product drawing:
Transparent 19 Inch Tft Capacitive Touchscreen , Waterproof Touch Screen Panel,Walll Mount Table Financial System
Transparent 19 Inch Tft Capacitive Touchscreen , Waterproof Touch Screen Panel,Walll Mount Table Financial System
