10 Points Anti Glare Touch Screen Panel 32 Inch Fast Sensitive Response
10 Points Anti Glare Touch Screen Panel 32 Inch Fast Sensitive Response
10 Points Anti Glare Touch Screen Panel 32 Inch Fast Sensitive Response
10 Points Anti Glare Touch Screen Panel 32 Inch Fast Sensitive Response
Specifications
Brand Name :
Touch-China
Model Number :
ZCC-4824
Certification :
CE, ROHS
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
13K per month
Delivery Time :
25 working days
Packaging Details :
Standard export package
Type :
Projected capacitve touch screen
Size :
32 inch
Touch points :
10
Structure :
G+G
IC solution :
ILITEK / EETI
Response time :
<10 ms
Description

10 Points Anti Glare Touch Screen Panel 32 Inch Fast Sensitive Response

Description:

The capacitive touch panel is usually made of two layers or more. The basic layer is the sensor, the other layer is the cover glass on the top. Both the sensor and cover glass can be customized based on customers’ detailed requirements. The normal structures can be G+G, G+F, G+F+F, P+G+G etc. Capacitive touch panel is different from resistive touch panel, when the touch panel is touched, people’s capacitance can be sensed by the touch panel. Then the chip can distinguish where the touch is.

Basic specification:

Size 32 inch
Total thickness 4.3±0.3mm
Outline of Cover Lens 757.12*450.6±0.5mm
Outline of ITO Sensor 732*427.41±0.5mm
Viewing Area 699.4*393.84±0.3mm
Active Area 700.92*395.58±0.3mm
Interface USB
Input voltage 5V
Response time 10ms
Report rate 100 HZ
Input method Hand writing or capacitive pen
Transmittance ﹥85%
Package list 32 inch Touch panel,controller board and USB cable
AG Haze Degree 6±3

FAQ:

Q. Does your products have CE & Rohs certificates?

A: Yes, of course.

Q. What’s the shipping method?

A: By sea / air / express, which methods to be used on the basis of customer’s requirements.

Q. What’s the payment methods?

A: T/T, 30% deposit before production, the balance before shipment.

Q: How many people are there in your factory?

A: There are about 500 people in our factory.

Q: What’s your lead time?

A: The lead time for both samples and mass production is 15 days.

10 Points Anti Glare Touch Screen Panel 32 Inch Fast Sensitive Response

What we believe in:

1.We guarantee customer satisfaction. Our staff is fully trained and knowledgeable about every product we offer, ready to assist you with whatever information is needed.

2. We have good resources of the raw materials, which make us capable of delivering the goods at stable cost and on time.

3. Our entire team works hard to always provide our customers with the best products and service on the market.

4. Feel free to contact us at any time with any questions, or to learn more about our high quality product for your unique company.

Product drawing:

10 Points Anti Glare Touch Screen Panel 32 Inch Fast Sensitive Response

10 Points Anti Glare Touch Screen Panel 32 Inch Fast Sensitive Response
