Anti Vibration Electronic Proximity Switch , Micro Inductive Proximity Sensor
Anti Vibration Electronic Proximity Switch , Micro Inductive Proximity Sensor
Specifications
Model Number :
SN04-D
MOQ :
100
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000only 8day
Place of Origin :
China
Brand Name :
Zhongde
Certification :
CE
Name :
Micro Inductive Proximity Sensor
Feature :
Anti Vibration
Material :
ABS
Voltage :
DC
Output Method :
NPN/PNP
Induction Method :
Normally open
Description

Anti Vibration Electronic Proximity Switch , Micro Inductive Proximity Sensor

Working principle
Electronic proximity switch is composed of three parts: oscillator, switch circuit and magnified output circuit.The oscillator will generate an alternating electric field.When metal object approaches this electric field and reaches the induction distance, whirlpool will generate in metal object, resulting in attenuation of vibration on and then stop.The change of vibration and stop of oscillator is treated by behind stage mag- nifide circuit and converted to switching sign, triggering driving control for non-contact detection.

Details

Two-wire

NPN/PNP

Normally open

DC

Parameter

Lag distance Less than 10% of the detection distance
Detecting objects Magnetic metal (detection distance is reduced when non-magnetic metal)
voltage DC : DC 12~24 (6~36V) pulse (p-p) below 10%
AC : AC 110~220V (36~250V) 50/60Hz
Current consumption N.P : ≤13mA
D : ≤0.8mA
A : ≤1.7mA
Control output N.P : ≤300mA
D : ≤200mA
A : ≤400mA
Loop protection N.P.D : reverse connection protection, surge absorption, load short circuit protection
A : surge absorption
Ambient temperature -30~+65°C (no icing, no condensation)
Ambient humidity -35~95%RH
Insulation resistance 50MΩ or more (DC500 megohmmeter) (between charging part and housing)
Withstand voltage AC 1000V 50/60HZ 1min (between charging part and Housing)
Temperature effect -30~+65°C: detection distance error ±15% at +23°C
-25~+60°C: detection distance error ±10% at +23°C
Voltage effect 6-36V (90-250V) : ±15% of detection distance error
10-30V (220V) : ±10% of detection distance error
Protection level IP67 (IEC)
Material Housing: ABS
Detection surface: ABS

Note:Please read the "Precautions" of the product manual before use.
