Dust Proof Safety Proximity Switch , Inductive Proximity Sensor Switch
Dust Proof Safety Proximity Switch , Inductive Proximity Sensor Switch
Specifications
Model Number :
PS17-5DY2
MOQ :
100
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000only 8day
Place of Origin :
China
Brand Name :
Zhongde
Certification :
CE
Name :
Inductive Proximity Sensor Switch
Feature :
Dust Proof
Material :
ABS
Voltage :
AC
Output Method :
NPN/PNP
Induction Method :
Normally closed
Description

Dust Proof Safety Proximity Switch , Inductive Proximity Sensor Switch

Description

Zhongde safety proximity sensors are designed as intrinsically safe equipment. Zhongde is a professional supplier, which has already got CE. These sensors have small volume, high reliability,simple operation and other advantages.

Details

Two-wire

NPN/PNP

Normally closed

AC

Parameter

Lag distance Less than 10% of the detection distance
Detecting objects Magnetic metal (detection distance is reduced when non-magnetic metal)
voltage DC : DC 12~24 (6~36V) pulse (p-p) below 10%
AC : AC 110~220V (36~250V) 50/60Hz
Current consumption N.P : ≤13mA
D : ≤0.8mA
A : ≤1.7mA
Control output N.P : ≤300mA
D : ≤200mA
A : ≤400mA
Loop protection N.P.D : reverse connection protection, surge absorption, load short circuit protection
A : surge absorption
Ambient temperature -30~+65°C (no icing, no condensation)
Ambient humidity -35~95%RH
Insulation resistance 50MΩ or more (DC500 megohmmeter) (between charging part and housing)
Withstand voltage AC 1000V 50/60HZ 1min (between charging part and Housing)
Temperature effect -30~+65°C: detection distance error ±15% at +23°C
-25~+60°C: detection distance error ±10% at +23°C
Voltage effect 6-36V (90-250V) : ±15% of detection distance error
10-30V (220V) : ±10% of detection distance error
Protection level IP67 (IEC)
Material Housing: ABS
Detection surface: ABS

Note:Please read the "Precautions" of the product manual before use.

Features

Reverse power protection, short circuit protection, can be directly connected to the PLC

Economical and simple operation

Long life and high reliability, strong environmental resistance

Red LED reality can detect sensor working status

IP67 protection structure (IEC)

About maintenance and overhaul

In order to keep the proximity sensor to work stably for longtime, the following regular examinations should be performed just like general control

1. Check the installation position of detected object and proximity sensor if any deviation,loosening or deformation exists.

2. Check the attached wires and connecting parts if any loosening,bad contact or wire breaking off exists.

3. Check if there is any metallic powder accumulation or not.

4. Check if the temperature condition and surrounding environment condition are normal or not.
