G139 Elevator NPN PNP Photoelectric Switch Aluminum Reset Button ODM / OEM
G139 Elevator NPN PNP Photoelectric Switch Aluminum Reset Button ODM / OEM
G139 Elevator NPN PNP Photoelectric Switch Aluminum Reset Button ODM / OEM
G139 Elevator NPN PNP Photoelectric Switch Aluminum Reset Button ODM / OEM
G139 Elevator NPN PNP Photoelectric Switch Aluminum Reset Button ODM / OEM
G139 Elevator NPN PNP Photoelectric Switch Aluminum Reset Button ODM / OEM
G139 Elevator NPN PNP Photoelectric Switch Aluminum Reset Button ODM / OEM
G139 Elevator NPN PNP Photoelectric Switch Aluminum Reset Button ODM / OEM
Specifications
Brand Name :
Winston/OEM
Model Number :
G139
Certification :
CE,ROSH
Place of Origin :
China,Zhejiang
MOQ :
1PCS
Price :
Negotiable
Payment Terms :
T/T,L/C,Paypal,Online Payment,RMB/USD
Supply Ability :
10000PCS/Month
Delivery Time :
3-15days after get payment.
Packaging Details :
Export standard carton box
Warranty :
2 Years
Condition :
Original new
Protection grade :
IP54
Shell material :
Aluminum/Plastic
Working temperature :
-25~+55℃
OEM :
YES
ODM :
YES
Detected object :
Transparent or opaque body
DC/AC Consumption current :
DC<15mA, AC<10mA
Theory :
Optical Sensor
Description
G139 Elevator NPN PNP Photoelectric Switch Aluminum Reset Button ODM / OEM

Mains features:


1 . high precision of repeated location
2 . Diversified exterior structures
3 . Many output forms
4 . High on-off frequency

5 . Good performance of anti-interference

Application illustration or photoelectric switch

1 . Built-in-power type photoelectric switch

2 . Detecting if beer is affixed with mark or not

3 . Check out the borken strip from carding machine

4 . Product accounting

Photoelectric switch Principle of photoeletric switch

The working principle of the photoelectric switch is that when the beam emitted by the emitter is blocked or partly reflected by the object, the beam by the emitter is blocked or partly reflected by the object, the beam receiver whereby makes a judgment and reacts.

Model composeition and definition of infrared ray photoelectric switch


G 18 3 A 10 N A □
—— —— —— —— —— —— —— ——
1 2 3 4 5 6 7 8

Technical Parameters:

Diffuse type Detection distance 1m
10-30VDC NPN NO G139-3A1NA
NC G139-3A1NB
NO+NC G139-3A1NC
PNP NO G139-3A1PA
90-250VAC NC G139-3A1PB
NO+NC G139-3A1PC
SCR Contro Hable silicon NO G139-2A1LA
NC G139-2A1LB
Relay output G139-2A1JC
Retroreflective type Detection distance 5m
10-30VDC NPN NO G139-3B5NA
NC G139-3B5NB
NO+NC G139-3B5NC
PNP NO G139-3B5PA
90-250VAC NC G139-3B5PB
NO+NC G139-3B5PC
SCR Contro Hable silicon NO G139-2B5LA
NC G139-2B5LB
Relay output G139-2B5JC
Through beam Detection distance 10m
10-30VDC NPN NO G139-3C101NA
NC G139-3C101NB
NO+NC G139-3C101NC
PNP NO G139-3C101PA
90-250VAC NC G139-3C101PB
NO+NC G139-3C101PC
SCR Contro Hable silicon NO G139-2C101LA
NC G139-2C101LB
Relay output G139-2C101JC
DC/SCR Control output DC:200mA,AC:300mA,Relay:2A
DC/AC Consumption current DC<15mA,AC<10mA
DC/AC Response time Dc<2ms,AC<20ms
Directional angle 3 . -10 .
Detected object transparent or opaque body
Working environment temperature 25~+55ºC
Intensity of illumination of working environment Sunlight under 1000LX incandescent lamp under 3000LX
Shell material Aluminum/Plastic
Protection grade IP54

Dimension

G139 Elevator NPN PNP Photoelectric Switch Aluminum Reset Button ODM / OEM

Product Picture

G139 Elevator NPN PNP Photoelectric Switch Aluminum Reset Button ODM / OEM
​

Our Services
  • Customized Samples are acceptable
  • Accept different payment methods, such as T/T, L/C, Western Union, Escrow to meet your different financial requirements
  • Welcome and accept 100% customers factory inspection before the production
  • Supply skills training including product basic knowledge, installation, operation, maintenance skills training for the local people
  • We provide 7 days 24 hours service!
