Aluminium UAS FPV Counter Drone Jammer Signal Jamming 200W IP65 Waterproof
Aluminium UAS FPV Counter Drone Jammer Signal Jamming 200W IP65 Waterproof
Aluminium UAS FPV Counter Drone Jammer Signal Jamming 200W IP65 Waterproof
Aluminium UAS FPV Counter Drone Jammer Signal Jamming 200W IP65 Waterproof
Aluminium UAS FPV Counter Drone Jammer Signal Jamming 200W IP65 Waterproof
Aluminium UAS FPV Counter Drone Jammer Signal Jamming 200W IP65 Waterproof
Aluminium UAS FPV Counter Drone Jammer Signal Jamming 200W IP65 Waterproof
Aluminium UAS FPV Counter Drone Jammer Signal Jamming 200W IP65 Waterproof
Specifications
Brand Name :
PTC
Model Number :
UAV-WP200W
Certification :
ISO 9000
Place of Origin :
Shenzhen China
MOQ :
1set
Price :
Contact Us
Payment Terms :
T/T, Western Union
Supply Ability :
50000
Delivery Time :
10-20days
Packaging Details :
Carton
Model NO. :
PTC-UAV-WP200W
Output Power :
200W
Working Frequency :
1.5g+2.4G+5.8g+900MHz+1.2g+433MHz
Jamming Distance :
100-1000meters
Waterproof :
IP65
Application :
Government+Oilfield+Airport Security
Description

Product Description

This high power Waterproof ANTI-DRONE JAMMER is elaborately designed as a domestic and international drone-controlling device by adopting advanced technologies both at home and abroad. It is an environment-friendly jammer. And designed to disturb low-altitude flying drone's remote control signals without influence on surrounding signals such as those for mobile communication, communication base station, car remote control and so on. The jammer is configured with 7 output channels (VHF/UHF/remote control /Wifi2.4G/5.8G/GPS positioning) to intercept drone's remote control signal, disturbing range can be up to 1km for option.

Product Parameters
Aluminium UAS FPV Counter Drone Jammer Signal Jamming 200W IP65 Waterproof
Basic Specifications
Working Frequencies: 7 Frequencies
Total Output Power: 210W
Jam Range: 100-1000meters
Power Supply: AC 220V
Product Size: 700*550*300mm(LxWxD)
Product Weight: appr.30kg

Channel # Working Frequency (±10MHZ) Channel Power(±3dBm)
CH1 300-450MHz 30W
CH2 450-600 MHz 30W
CH3 600-800 MHz 30W
CH4 800-1000 MHz 30W
CH5 1000-1200MHz 30W
CH6 2400-2500MHz 30W
CH7 5725-5850MHz 30W
Total Working Channels 7 channels
Total Working Output 210W
Shielding distance 100meters-1km
Jamming Objects UAV image transmission, flight control link, navigation signal
Power Supply AC: 110-240V
Antenna High gain Directional antenna
Power consumption 600W
Waterproof Level IP65
Weight 40Kg
Size(Length × width × height)

700*550*300mm(LxWxD)

no included antennas
Humidity 5%-95%
Operation temperature -20 to +50℃

Product Advantages

Features and Advantages

  1. Ultrahigh frequency board-band jamming technology
  2. Wide coverage of 7 Frequencies with high effective power.
  3. Waterproof designed
  4. Long jamming Range up to 1km.
  5. High Power and Friendly use
  6. Support high gain Omni Antennas and Directional Panel Antennas
  7. Effective segmentation to block each drone controlled signals.
  8. Imported chips, slow start circuit design can avoid the sparking phenomenon caused by mechanical switch, high integration and stable operation. standing wave and other fault alarms, the drone signal jammer will automatically cut off the failed module to avoid damage to the drone shield.
Detailed Photos

How to Use:
Put the Drone jammer on the higher places and switch on then jammer works, it will cut off the signal between the controller and the drones. The drone will not be able to receive any control signals or transmit any camera signals back to the controller and drop down. The drone will be officially MIA (missing in action).
Aluminium UAS FPV Counter Drone Jammer Signal Jamming 200W IP65 Waterproof
Product Application

Aluminium UAS FPV Counter Drone Jammer Signal Jamming 200W IP65 Waterproof
Applications:
Any sensitive locations where the drones/UAVs are not allowed to use, like Government, Oilfield, Homeland Security, Large Gathering Place, Counter-terrorism, Ar-my Security, Airport Security, Petrochemical Industry, Sports Venues, VIP Convoy Protection, Schools and Universities
etc.
