Equipment Operating Environment Requirements

1. The ground of the site is required to be level, and the site load is not less than the design requirements.

2. The operating platform needs clean space to reduce dust ingress. It is best to have ventilation ducts in the workshop to facilitate ventilation.

3. Industrial power standard 380V 50Hz 3P, voltage can be customized according to user needs.

4. The factory is equipped with power distribution cabinets, compressed air and other supporting equipment.

5. The equipment needs to be equipped with a cooling system. Two buckets / water tanks can be used with a cooling pump to recycle water resources.

6. The room temperature of the plant should be no more than 28 ° C.

7. The vertical extrusion equipment extrudes from the top to the bottom. The equipment is installed on the platform or floor with a space height of about 2.8 meters. The effective distance in the longitudinal direction of the device needs to be considered, and a sufficient height must be guaranteed under the fixed circular hole of the device to meet the requirements of the length of the extruded PTFE rod.

8. Horizontal extrusion equipment needs to consider the effective distance in the horizontal direction of the equipment, and it is necessary to ensure the length of the PTFE rod. The equipment includes a mold length of 4-7 meters (excluding the length of the extruded finished rod), a width of 1.2 meters, a height of 1.8 meters.

Equipment Parameter

Equipment And mold Maintenance

1. Regularly check the height, cleanliness and temperature of the hydraulic oil.

2. It is recommended to replace the hydraulic oil every six months.

3. Replaced worn seals timely.

4. The mold should be cleaned and maintained in time, and the surface should be coated with a thin layer of protective oil.

5. Carefully handle the temperature sensor of the heating coil, and store it properly.

Accessories And Spare Parts Description

1. The equipment is composed of main machine, a hydraulic station, a control cabinet, an automatic feeder, holders, heating cavities, molds and other accessories. Equipment necessary accessories are sent to customers with the equipment.

2. The list of necessary accessories for the equipment is sent to the user with the equipment.

3. When the user purchases our company’s equipment, in addition to the necessary accessories, we will provide the necessary spare parts to the user to replace and repair the equipment. Spare parts are standard parts and can be purchased in the local market.

Process Guidance

1. Due to the special technology of the equipment, customers can go to the factory to learn about the installation, commissioning, operation, mold change, maintenance, process guidance of the equipment for free before delivery.

2. If you are unable to come to our company to study due to inconveniences such as distance, personnel, time, we can arrange for engineers to come to guide the installation, commissioning, operation, mold replacement, maintenance, and process guidance of the equipment under the agreement of the other party.

3. We can also conduct remote guidance. Users can choose other methods such as telephone, video, email, etc. to learn about equipment installation, commissioning, operation, mold change, maintenance, process guidance, etc.of the equipment.

The advantages of a Polymer PTFE Rod Ram Horizontal Extruder Machine include:

• High production efficiency: The machine is designed to extrude Polymer PTFE rods horizontally, allowing for continuous and efficient production.
• Precise control: The machine is equipped with advanced control systems that ensure precise control over the extrusion process, resulting in consistent rod dimensions and quality.
• Versatility: The machine is capable of extruding Polymer PTFE rods of various diameters and lengths, making it suitable for a wide range of applications.
• Easy operation: The machine is designed with user-friendly controls and interfaces, making it easy to operate and control the extrusion process.
• Low maintenance: The machine is built with high-quality materials and components, reducing the need for frequent maintenance and ensuring long-term durability.
• Energy efficiency: The machine is designed to minimize energy consumption, making it cost-effective and environmentally friendly.
• Safety features: The machine is equipped with safety devices and mechanisms to ensure operator safety during the extrusion process.
• Customization options: The machine can be customized to meet specific production requirements, allowing for flexibility and adaptability.

After Sales Service

1. From the date of receiving the machine, the warranty period of all machine accessories is one year. We provide free maintenance guidance service during the warranty period.

2. If there is any problem with the accessories outside the warranty period, please contact us in time to explain the problem, and we will provide follow-up resolution within 24 hours.

3. If we have a local distributor, we can contact the local distributor for cooperation.

4. All questions about the equipment can be consulted to us by mail, video, telephone, etc.

Service Phone:+86-0519-83999079

PTFE Rod Line Automatic Feeding Equipment

Vacuum automatic feeding, including compressed air reverse blowing system, start feeding system, wash hose, suction gun, vacuum generator, PCB controller,throughput 30-300 kg/h, diameter 150mm and height 600mm, set automatic feeding time and discharging time, powder flow is controllable, all stainless steel production, intelligent control.

The mixing barrel is 600mm in diameter and 700mm in height, with a 2.2kw reduction motor, a stirring speed of 15-25 turns/min, 8-10mm thick bottom plate, and a feeding capacity of 75-90kg.

SKVQC-10 Configuration List:

Technical Parameters:

Related Optional Equipments

Please contact us for other PTFE processing equipment.
