Specifications
Place of Origin :
China
Brand Name :
B&C
Certification :
SGS,UL, CE,IOS9001,ISO14001
Model Number :
PTFE O-Rings - 001
Size :
Diametre 1~2000mm
Thickness :
0.3-50mm
MOQ :
50pcs
Price :
Negotiable
Packaging Details :
Ply-Wooden Cases
Delivery Time :
10-20days
Payment Terms :
T/T, LC
Supply Ability :
110Tons/month
Type :
PTFE O-Rings
Applications :
Pipe Fittings
Color :
White
Feature :
Anti-Corrosion|Non-Stick|High Chemical Stability
Product Name :
PTFE Balls
Temp :
-180 °C - 260 °C
Density :
2.10 - 2.30 g/cm³
Description

Non-Stick PTFE Balls , 2.30 g/cm³ PTFE O-Rings For Pipe Fittings Non-Stick

Quick Detail:

1.special high chemical stability

2.low co-efficient of friction

3.nonstick

4.High quality and competitive price

Description:

PTFE O-Ring is chosen suspended aggregation PTFE/ resin shaped or cutting into

processed. compared with other plastics with a corrosion resistant chemical characteristics

Naiwen Merit.It has been widely used as a sealed materials.

PTFE O-Rings are produced following the standard dash sizes as for rubber sizes. They are circular

rings with an ID and a cord diameter, which gives various advantages on the rubber O-Rings.

Applications:

1.Machinable production liner,

2.complex piece,

3.three-, four-way,

4.Elbow

5.pipe fittings,

6.wide turning plate,

7.chemical container equipment

Specifications:

Specification:

Item

Unit

Range of work

Inter Ф

mm

1~2000mm

Outer Ф

mm

2~2000mm

Thickness

mm

0.3~50mm

Filled Materials

Graphite ,Glass Fiber , Carbron fiber , Bronze

Technical Data:

PROPERTIES

UNIT

RESULT

Apparent density

g/cm3

2.10-2.30

Tensile strength (min)

Mpa

≥25

Ultimate elongation (min)

%

≥200

Working Temp

°C

-180 ~ 260

Melting point

°C

327

Produce Max. Temp

°C

385

Hardness Rockwell

M65

Remarks:

PTFE O-Rings is available in variety of colors, diameter, thickness to meet your specific requirements.

Competitive Advantage:

1.Excellent Chemical property

2.Virgin and recycled materials available

3.Any sizes available

4.Fast Usually
