40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
Specifications
Place of Origin :
Henan, China
Brand Name :
ZENGTUO
Supply Ability :
5000 Unit/Units per Month
MOQ :
2 units
Price :
$7,900.00/units 2-9 units
Warranty :
1 Year
After-sale Service :
Online technical support
Application :
Warehouse
Material :
Sandwich Panel
Use :
Warehouse
Product Type :
Detachable Container
Design Style :
Chinese
Product name :
Container House Container Home
Keyword :
Mobile Living Container House
Advantage :
Eco friendly, Fast install,Wind proof,light weight,
Service Life :
At least 35 years
Structure :
Q235/Q345 light steel frame
Applications :
Office buildings,hotel,mall,mining area,etc
Floor :
MGO Board,Fiber Cement Board,PVC Board
Wall :
Sandwich Panel Wall
Standard Size :
5800*2400*2890mm or Custom requirement
Certificate :
ISO9001-2000,ISO14001
Description
Products Description
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame

Size
Standard size or customized
Loading
1x40HQ can load 1-6 units
Weight
2800 kg/unit
Floor load
250 kg/sqm
Roof load
100 kg/sqm

Design And Installation

40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
Installation service
Option size
20ft,40ft,etc...We also had special size for 2.9M height
Main material
Galvanized steel structure with sandwich panel wall and doors, windows, etc.
Weight
3200kgs
Service life
60-70 years
Color
White, blue, green, brown, or customized
Columns
3mm Hot galvanized steel structure
Steel structure
3mm Hot galvanized steel structure with 4 corner casts and
(1)18mm fiber cement board;
(2)1.6mm PVC flooring;
(3)50mm rock woll ,eps or PU sandwich panel
(4)Galvanized steel base plate.
Wall
50/75/100mm EPS/Rock wool/PU Sandwich Panel
Roof
3-4mm Hot galvanized steel structure with 4 corner casts and
(1)Galvanized steel roof covering;
(2)50mm -70mm eps sandwich panel or PU sandwich panel ;
(3)50mm -70mm eps sandwich panel or PU sandwich panel ;
Door
Made of steel/aluminum frameDimension W870*H2040mm, furnish with a handle lock with 3 keys
or sliding glass door W1500*2000mm.
Window
Made of PVC/aluminum fame.Dimension W800*H1100mm, glazed with double glass in a thickness of 5/8/5mm.
Connection kits
PVC Connection kits for ceiling, floor and walls.
Electricity
3C/CE/CL/SAA Standard,with distribution box, lights, switch, sockets, etc.

advantage

Fast installation: 2 hours/set, save labor cost;

Waterproof: without wood ceiling,wall;

Simple foundation:just need 12pcs concrete bolck foundation;

40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
Customization available
Door
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
.Window
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
Floor
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
Alternative type
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
Certifications
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
Packing & Delivery
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
40ft Foldable Mobile Expandable Container Home Q235 / Q345 Light Steel Frame
