Polyurethane Cool Gel Pads Making Machine PU Gasket Dispensing Machine
Polyurethane Cool Gel Pads Making Machine PU Gasket Dispensing Machine
Polyurethane Cool Gel Pads Making Machine PU Gasket Dispensing Machine
Polyurethane Cool Gel Pads Making Machine PU Gasket Dispensing Machine
Specifications
Brand Name :
Yongjia
Model Number :
Gasket Casting Machine
Certification :
CE
Place of Origin :
Jiangsu, China
MOQ :
1 Set/Sets
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union,
Supply Ability :
100 Set/Sets per Month High Quality vacuum Polyurethane Cabinet Door Sealing Strip
Delivery Time :
45-60 days
Packaging Details :
sea worthy wooden box for Polyurethane PU Dispensing Machine For Weatherstrip Profiles Making
Product name :
PU Gel Dispensing Machine
strength 1 :
self-cleaning filter
strength 2 :
precise metering
feeding system :
automatic feeding system
control system :
PLC control system
foam type :
pu gel
Description
Polyurethane Cool Gel Pads Making Machine PU Gasket Dispensing Machine
Introduction Of PU Gel Making Machine:

PU Gel Dispensing Machine is mainly used to produce gel pad, gel cushion, gel pillow, gel mattress and many other gel products.

Specifications:
Power ψ220V/60hz 8KW(customized by customer requirement)
Tank capacity 50L/50L/50L
Quantitative pump capacity (HW-AP50)9m³/rev (HW-AP30)6m³/rev
Output 5~30g/s
Accuracy ±1%
Air source 4kg/m³ ~ 6kg/m
Raw material barrel pressure ≤1.5kg/m³
Raw material circulation pressure ≤10kg/m³
Raw material allowable viscosity ≤2500cps

Product Features:

1. Servo motor drives high-precision pump measurement to ensure quantitative and uniform mixing ratio.

2. High-speed dynamic mixing glue gun, convenient and simple to maintain, with automatic cleaning function to ensure no dripping.

3. PLC programming control of gel sheet production machinery and equipment.

4. Large touch screen operation, easy to learn, with parameter locking function, to prevent accidental modification of parameters and ensure quality.

5. Imported electrical appliances and servo motor control to ensure the proportion and precision of the glue.

6. The material tank is equipped with stirring and heating and heat preservation functions. The temperature is within 80℃, and the controllable accuracy is plus or minus 2℃.

Machine Details:

Tank information:

A tank is with mixing unit

A tank: 30L, 1PCS and B tank: 30L, 1PCS

Tanks are with negative pressure auto feeding system

Tanks are with liquid level showing unit l

Tank with 304 stainless steel

Tanks remaining material is with auto alarm system

Tanks can be vacuum to get out the bubbles inside of the material

Mixing head details:

Mixing head is made of stainless steel and alloy metal

The mixing head is static mixing

The mixing head is easy cleaning and well sealing

Metering pump:

Ratio can be adjustable from 1:1 to 10:1

Metering pump is driven by servo motor

Metering pump is gear pump and wear-resistant

It is Taiwan brand

Application:

Polyurethane gel is a dense material, a solid in liquid. Its special touch is unmatched by other materials. It has viscoelastic properties and is the best energy absorption and cushioning material. Gel is widely used in modern society and can be used in many different applications, including computer mouse pads/keyboard wrist rests, memory pillows, mattresses, bicycle seats, motorcycle seats, insoles, medical equipment and other cushion components.

Polyurethane Cool Gel Pads Making Machine PU Gasket Dispensing Machine

Certifications:
Polyurethane Cool Gel Pads Making Machine PU Gasket Dispensing Machine
