Specifications
Brand Name :
D&T
Model Number :
DTC-E2012
Certification :
ce
Place of Origin :
CN
MOQ :
1set
Price :
USD20000~40000/SET
Payment Terms :
T/T, L/C, Paypal
Supply Ability :
20 Sets Per Month
Delivery Time :
20days
Packaging Details :
packed with pvc film into 20 container
Item :
CNC 2D EPS cutting machine
Type :
DTC-E2012
Product Size :
2000*1300*1000mm
Cutting Line Diameter :
0.5-1.2mm
Control System :
Industrial Computer
Cutting Speed :
0-1.5m/min(adjusted)
Precision :
±1mm
Power :
13.5kw,380v,50hz
Weight :
1200kgs
Color :
as cliebts requirement
Name :
eps cutting machine
Warranty :
1 year
Description

Auto Expander Polystyrene Hot Wire Foam Cutting CNC Machine For EPS 2D Shape


CNC 2D EPS cutting machine/polystyrene foam cutting machine/
styrofoam cutting machine/ eps block cutter/ electric hot wire eps cutter


1. Technical Data of 2D EPS cutting machine

TECHNICAL DATA
TypeDTC-C2012DTC-E3012DTC-E6012
Max. Product Size2000*1300*1000mm3000*1300*1300(mm)6000*1300*1300(mm)
Cutting Line0.5~1.2mm
Control SystemIndustrial Computer
SoftwareD&T ProfilerD&T ProfilerD&T Profiler
Cutting Speed0~1.5m/min0~1.5m/min0~1.5m/min
Person ±1mm
Power13.5kw, 380v, 50hz14.5kw, 380v, 50hz14.5kw, 380v, 50hz
Overall Weight1200kg1500kg2000kg
























2. Description Of 2D EPS cutting machine

Suit for: Polystyrene
Cutting line: Hot Wire

D&T series 2D EPS cutting machine is a special cutting machine,
which is for complex shapes of EPS products.
THis kind of cutter has one or sevaral cutting lines for different production request.

All the machines are driven by the remarkable D&T Profiler software,
which speeds up the design process and enables
the operator to obtain the best yield from the foam block.


It includes: All Motor will stop when the safety door be opened;
Exigency button on both machine and control box for accident;
brake system when cutting line broken.

FAQ


1. Q:Are you a factory ?

A:Yes,We are a manufacturer and doing the foam machines since 2006.

2. Q: Which drawing software do you use?

A: Auto CAD.

3. Q: Whether your engineer can come to our factory for installation of the machine?

A: Yes, sure.

4. Q: Can you import DXF files from another source?

A : yes. Any DXF files is acceptable.

5. Q:The other fast wire machine had dust extraction and filtering. Does this machine also have dust extraction?

A : Yes, include it.

6. Q: What countries have you sold to?

A: Canada,Mexico,Brazil,Australia,Singapore,Malaysia,UAE,Yemen,Qatar,Algeria etc.

7. Q: What safety controls are on the machine?

A: There are urgence bottoms on the control box and machine for accident to stop the mahicne.

There are two fence around the cutting frame, the machine will stop when you open the fence.



Finished Products:

Full-Automatical Durable Hot Wire Foam Cutting CNC Machine For EPS 2D Shape Full-Automatical Durable Hot Wire Foam Cutting CNC Machine For EPS 2D Shape
