Menswear rib collar metal zip through charcoal mock suede baseball jacket TW66041
Description
Shell fabric
|
100%polyester 100%viscose base |
Lining
|
210T charcoal lining |
RIB
|
100%polyester |
Trims list
Trim
|
Position | Quantity | Size | Color |
metal zip
|
CF | 1 | #5 | polished sliver |
Branded puller
|
CF | 1 | polished sliver | |
print label
|
LSW chest | 1 | 22x22mm | black print |
Styling Details
Front:
1) 1x1 rib baseball collar in solid but tonally darker charcoal colour.
2) Collar attached to body with footstitch.
3) Dropped shoulder and additional shoulder cutline, finished with footstitch.
4) No5 metal zip at CF in shiny silver colour, with branded zip puller.
5) CF zip finished with footstitch.
6) 2cm welt pkt, diagonal placement, Finish with footstitch.
7) Welt pkt insertion as development sample but finish with footstitch.
8) Rib hem but finish at CF as per attached photo.
9) Rib hem and cuff attached with footstitch finish.
10) Thick topstitch thread quality, matching body fabric colour.
11) Longsleeve with cutline on front and back of sleeve as development sample, finish with footstitch.
12) Rib cuff attached with footstitch.
Back:
13) Remove cutline from CB and change to diagonal shoulder cutline from collar to sleeve cutline (same as on front shoulder). Finish with footstitch
Inside:
14) Body fabric hanger loop inserted into the neck seam.
15) Body and sleeves lined with 210T polyester lining.
16) Pleat construction for lining at CB.
17) Inside facing in body fabric.
18) Vertical wallet pkt placement on inside LHSW with silver concealed snap button.
Mearsurement
MEASUREMENTS | Tolerances | XXS | X-Small | Small | Medium | Large | X-Large | XX-Larg |
Collar Depth @ Centreback Neck | 0/0 | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
Collar measurement along neck seam | 5/5 | 43 | 44 | 46 | 48 | 50 | 52 | 54 |
Across Back Neck (HSP to HSP) | 5/5 | 16.4 | 16.9 | 17.7 | 18.5 | 19.3 | 20.1 | 20.9 |
Neck Drop (seam to seam) | 5/5 | 8.2 | 8.2 | 8.6 | 9 | 9.4 | 9.8 | 10.2 |
Across Front Mid-Armhole or Yoke | 5/5 | 36 | 37.1 | 39.3 | 41.5 | 44.1 | 46.7 | 49.3 |
Across Back Mid-Armhole or Yoke | 5/5 | 38.5 | 39.6 | 41.8 | 44 | 46.6 | 49.2 | 51.8 |
Half Chest at Underarm | 10/10 | 46.5 | 48.5 | 52.5 | 56.5 | 61.5 | 66.5 | 71.5 |
Half Hem Width - Straight Across | 10/10 | 38 | 40 | 44 | 48 | 53 | 58 | 63 |
Shoulder Seam ex Neck Trim | 5/5 | 12.5 | 12.9 | 13.7 | 14.5 | 15.3 | 16.1 | 16.9 |
Sleeve Length (including Cuff) | 10/10 | 65.5 | 66 | 67 | 68 | 69 | 70 | 71 |
Half Armhole (Diagonal) | 5/5 | 22.5 | 23 | 24 | 25 | 26.5 | 28 | 29.5 |
Half Bicep at Underarm Pt | 5/5 | 18.5 | 19 | 20 | 21 | 22.5 | 24 | 25.5 |
Half Cuff Width | 5/5 | 8.5 | 8.5 | 9 | 10 | 11 | 12 | 13 |
rib depth | 0/0 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 |
Front Length (from HSP) | 10/10 | 65 | 67 | 69 | 71 | 73 | 75 | 77 |
C/Back Length from Neck Seam | 10/10 | 63 | 65 | 67 | 69 | 71 | 73 | 75 |
Half Cuff Width at rib seam | 10/10 | 11.5 | 11.5 | 12 | 13 | 14 | 15 | 16 |
Half Elbow at Mid Underarm | 10/10 | 15 | 15.5 | 16.5 | 17.5 | 19 | 20.5 | 22 |
Half Waist (16cm down frm u/arm) | 10/10 | 42 | 44 | 48 | 52 | 57 | 62 | 67 |
Half hem at rib seam | 10/10 | 40.5 | 42.5 | 46.5 | 50.5 | 55.5 | 60.5 | 65.5 |
