Mechanical Seal SLH-4G-4052 Double Seal 70mm For SLH-4G Pumps Model 1000/2000/3000/4000
Mechanical Seal SLH-4G-4052 Double Seal 70mm For SLH-4G Pumps Model 1000/2000/3000/4000
Mechanical Seal SLH-4G-4052 Double Seal 70mm For SLH-4G Pumps Model 1000/2000/3000/4000
Mechanical Seal SLH-4G-4052 Double Seal 70mm For SLH-4G Pumps Model 1000/2000/3000/4000
Mechanical Seal SLH-4G-4052 Double Seal 70mm For SLH-4G Pumps Model 1000/2000/3000/4000
Mechanical Seal SLH-4G-4052 Double Seal 70mm For SLH-4G Pumps Model 1000/2000/3000/4000
Mechanical Seal SLH-4G-4052 Double Seal 70mm For SLH-4G Pumps Model 1000/2000/3000/4000
Mechanical Seal SLH-4G-4052 Double Seal 70mm For SLH-4G Pumps Model 1000/2000/3000/4000
Mechanical Seal SLH-4G-4052 Double Seal 70mm For SLH-4G Pumps Model 1000/2000/3000/4000
Mechanical Seal SLH-4G-4052 Double Seal 70mm For SLH-4G Pumps Model 1000/2000/3000/4000
Specifications
Brand Name :
JR
Model Number :
SLH-4G-4052
Certification :
iso9001
Place of Origin :
MADE IN CHINA
MOQ :
1PC
Price :
Negotiated
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
1000PC/Month
Delivery Time :
20-30DAYS
Packaging Details :
box as requirement
Material :
TC TC FKM
Function :
for Oil Pump, Water Pump
Transport Package :
box
HS Code :
848420090
Specification :
Gorman Rupp Cartridge Mechanical Seal
Certificate :
ISO9001
Type :
Gorman Rupp pump
Standard :
Standard
Size :
SLH-4G-4052 John crane mechanical seal
Name :
SLH-4G-4052 John crane Seal
Description

Double Mechanical Seal SLH-4G-4052 Seal 70mm For SLH-4G Pumps Model:1000/2000/3000/4000

Operational Conditions:

  1. Burg DF-SGR Mechanical Seals For Burn SLH/SLH-4G Screw Pump
    Operations Conditions:
    Temperature: -40°C~220°C
    Pressure: ≤12Bar
    Speed: ≤ 12 m/Sec

    Materials:
    * Rotary Face: Carbon, SiC, TC
    * Stationary Seat: Seat: SiC, TC
    * O-rings: NBR, EPDM, VIT, Aflas, FEP, Kalrez, Chemraz etc.
    *     Metal parts: SS316, hastelloy C, AM350
    Our double mechanical seal for screw pumps: 30mm, 40mm, 50mm, 55mm and 80mm.
    EDH-040-ZZH07/C8H67---part NO. S250895
    EDH-070-ZZH07/C8H67---part NO. 902235 S250933
    SLH80-040----28A274-001
    SLH125-055---28A274-001

    complete rang of mechanical seals for SLH pumps:
    EDH 30mm QQE/QBEGG SLH 50
    EDH 40mm QQE/QBEGG SLH 80
    EDH 55mm QQE/QBEGG SLH 125
    EDH 80mm QQE/QBEGG SLH 180

    complete rang of mechanical seals for SLH-4G pumps:
    EDH 30mm Q1Q1E/BW1EGG-4G SLH 4G1000
    EDH 40mm Q1Q1E/BW1EGG-4G SLH 4G2000
    EDH 50mm Q1Q1E/BW1EGG-4G SLH 4G3000
    EDH 80mm Q1Q1E/BW1EGG-4G SLH 4G4000


Performance Capabilities:

mechanical seal Replacement for sale
Operational Condtions
Size
Material
Temperature:
-40℃ to220℃, depend on o-ring material
30-100MM
Face: TC
Pressure: Up to25 bar
Seat: TC
Speed:Up to 20m/s
Elastomer: FKM
End Play /axial float Allowance:±1.0mm
Other Metal Parts : SS316, hastelloy C, A

Mechanical Seal SLH-4G-4052 Double Seal 70mm For SLH-4G Pumps Model 1000/2000/3000/4000Mechanical Seal SLH-4G-4052 Double Seal 70mm For SLH-4G Pumps Model 1000/2000/3000/4000Mechanical Seal SLH-4G-4052 Double Seal 70mm For SLH-4G Pumps Model 1000/2000/3000/4000

We are engaged in manufacture and installation exporting and wholesaling quality range of Industrial Seal, Single Spring Seal, Balance and Unbalance Spring Seal, External Mounted Seal, PTFE Bellow External Mounted Seal, Catridge Balance Seal, Multiple Spring Balance Seal, Dry Running Reverse Balance Seal, Agitator Double Acting Unbalance Seal, Single Conical Helical Spring, Rubber Bellow Seal, Multi Spring Seal, Metal Bellow Seal, Elastomer Bellow Seal, Conical Spring Seal, Air Condition Compressor Seal, Auto Cooling Seal, Metallic Bellow Seal,

All ranges of mechanical seals for Flygt Pumps, Grundfos Pumps, Pumps, APV Pumps, Grindes Pumps, Fristam, ABS, Alleeiler, EMU, GEA

Tunchenhagen, Godwin, Hidrostal, Hilge, Johnson, Lowara, Waukesha, Vogelsang Pumps etc.

At the meantime, we could manufacture seals according to your sample or drawing, and design as your request,Customization: Changes of materials for getting other operating parameters are possible. Contact us with your requirements.

Question 1: Are you a factory or a trade company?
Answer: We are a factory and have our top sales for the trade service.

Question 2: Can I try to get a SAMPLE before the order?
Answer: Sure. You can ask for the samples. Usually they're free.

Question 3: Where is your factory located? How can I visit there?
Answer: Our factory is located in Ningbo, China. You can fly to Ningbo or Shanghai airport directly. All our clients, from home or abroad, are warmly welcome to visit us!

Question 4: How does your factory do regarding quality control?
Answer: Quality is priority. We always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ISO9001 authentication.

Question 5: How about the lead time?
Answer: Within10-20 days after getting the prepayment.

Question 6: How can we pay?
Answer: For small sample shipping cost, you can pay either by paypal or by T/T. And by T/T at sight for large amount of the order.

Question 7: If OEM available?
Answer: Yes, we provide all of our products OEM /ODM service.

Question 8: If I can buy pumps or pump parts from your company?
Answer: Yes , we also provide pumps and pump parts, such as Lobe pumps, Compound & homogeneous pumps, Homogeneous & emulsification pumps and so on
