Unbalanced Crane Mechanical Seals 19.05mm 25.4mm For Waster Pumps 92500150
Unbalanced Crane Mechanical Seals 19.05mm 25.4mm For Waster Pumps 92500150
Unbalanced Crane Mechanical Seals 19.05mm 25.4mm For Waster Pumps 92500150
Unbalanced Crane Mechanical Seals 19.05mm 25.4mm For Waster Pumps 92500150
Unbalanced Crane Mechanical Seals 19.05mm 25.4mm For Waster Pumps 92500150
Unbalanced Crane Mechanical Seals 19.05mm 25.4mm For Waster Pumps 92500150
Unbalanced Crane Mechanical Seals 19.05mm 25.4mm For Waster Pumps 92500150
Unbalanced Crane Mechanical Seals 19.05mm 25.4mm For Waster Pumps 92500150
Specifications
Brand Name :
Bogeman
Model Number :
E- 520
Certification :
ISO SGS
Place of Origin :
Guangzhou, China
MOQ :
5/PCS
Price :
US $ 0.6-28.8/PCS
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
80000/month
Delivery Time :
2/day
Packaging Details :
Carton
model :
E EA520
speciflcation :
Shaft hole 7.925-28.575mm
material :
CAR CER SSIC TC NBR EPDM
usage :
unbalanced
traemark :
Bergman
origin :
Guangzhou, China
Description

Unbalanced Crane Mechanical Seals 19.05mm 25.4mm For Waster Pumps 92500150

Mechanical Seal 92500150 E 1/2 5/8 3/4 1 Pump Seal Mechanical Seal

Basic Info.

Model NO.

BGM-E

Type

HU5

Balance

Balanced

Trademark

Bergman

Transport Package

Box

Specification

10cm*10cm*10cm

Origin

China

HS Code

84842000

Crane Mechanical Seals Replacement pump seal for Circ-Master, Flo-Master, XP, XP2, XP2e and XP3 HP/CP hot tub pumps.

This seal fits the following pump models:

Circ-Master / Hush pump side discharge (HP) models and the centre discharge (CP) models.
Flo-Master series side discharge and centre discharge models.
Aqua-Flo XP2, all models
Aqua-Flo XP2e, all models
Aqua-Flo XP3, all models
Aqua-Flo by Gecko part #: 92500150
Standard seal suitable for pumps used in standard Bromine/Chlorine environments

Model

d1(inches)

d7

d3

d6

d2

l

l3

BGM E-5/16 "

7.925
9.520
12.700
15.875
15.875
15.875
19.050
19.050
25.400
28.575

25.4

27

16

20.63

24.6

8

BGM E-3/8"

22.225

23.8

14.3

17.42

22.22

6.2

BGM E-1/2"
BGM E-5/8"

25.4

26.97

17.45

20.63

22.8

6.2

30.1

30.94

20.63

23.8

26.5

8.7

BGM E-5/8"H

31.75

30.94

20.63

23.8

30

10.3

BGM E-5/8 "K

31.75

30.94

20.63

23.8

28.5

10.3

BGME-3/4"H

34.925

34.11

23.8

26.87

30

10.3

BGM E-3/4"c

34.925

34.11

23.8

26.87

28.5

10.3

BGM E-1"

41.275

42.85

30.15

33.33

31.73

11.1

BGM E-11/8 "

44.45

46

33.5

36.5

31.75

11.1

Unbalanced Crane Mechanical Seals 19.05mm 25.4mm For Waster Pumps 92500150

We are a manufacturer. All seals have bulk inventory and can be shipped to you quickly. We promise to ship you in small quantities within 3 days.Advanced technology, excellence, replace original

1. Different models of mechanicals seals for a wide variety of Grundfos® pumps, among them: CR(N), NB, NK, CLM, LP, TP, etc. Available in diverse combinations of materials and different diameters: 12, 16, 22, 28, 33, etc. Also mechanical seals for Sarlin®. Division of waster pumps. Available in various materials: silicon-graphite carbide, silicon carbide-silicon carbide; combined with EPDM and FKM elastomers.
2. Mechanical seals are available for different references Gorman-Rupp® pumps. Special models for the transfer of clean water, sewage, oil industry, agriculture and others.
GRN-38'1
3. Mechanical seals for Fristam® pumps. Wide range of models and materials in the most standard diameters: 22,30 and 35 mm. Different assembly possibilities for the most well-known pump models: FP, FL and FT.
4. Broad range of mechanical seals compatible with Flygt® and Grindex® waste water pumps. These mechanical seals are characterized by their easy and fast installation, without having to make any modification to the pump. Manufactured in stainless steel and in solid tungsten carbide. Special tools are not necessary for their installation.
5. Allweiler, Simple design of mechanical seals simple but with special measures for this type of pump.
6. Different models of mechanical seals compatible for Alfa-Laval® pumps series CM, FM, MR, LKH,GM and ALC. Also the models for the range of lobular SSP and SR pumps. Mechanical seals in different combination of materials tungsten carbide, silicon carbide, graphite; combined with different types of elastomers: NBR, EPDM and FKM.
7. Mechanical seals for ABS® submergible pumps specific wastewater treatment. Different models of mechanical seal available: oil chamber mechanical seal and water mechanical seal.

Unbalanced Crane Mechanical Seals 19.05mm 25.4mm For Waster Pumps 92500150Unbalanced Crane Mechanical Seals 19.05mm 25.4mm For Waster Pumps 92500150


Fixing and Applying Directions of Mechanical Seals


1. Select Appropriate mechanical seal to match the materials according to work conditions and host machine equipment.
2. The radial acting deviation for the shaft(shaft sleeve) of the installed mechanical seal shall be 0.04mm by maximum
while the axial movement value of the rotor shall be no more than 0.1mm.
3. The seal cover (or shaft cover) of the stationary ring of the installed mechanical seals,the vertical degree of the seal
face should be 0.04mm by maximum.
4. hen installing the mechanical seals,the shaft(shaft sleeve),seal chamber,seal face as well as the mechanical seal
must be cleaned in order to keep from any medium to sealing part.
5. When conveying medium of over high or low temperature,with medium which are easy catch fire,easy for explosion.
Related mechanical seal standards must be referred to take appropriate measures such as quench,rinsing,coolong and
filtrating.
6. Before the machine starts running,the hermetic compartment shall be full of medium and well lubricated.Dry friction
which may lead to the damage of the air-tightness is strict forbidden.
