600W 24VDC15A Power Backup Inverter 230VAC/50HZ Single Phase Wall Mount
600W 24VDC15A Power Backup Inverter 230VAC/50HZ Single Phase Wall Mount
600W 24VDC15A Power Backup Inverter 230VAC/50HZ Single Phase Wall Mount
600W 24VDC15A Power Backup Inverter 230VAC/50HZ Single Phase Wall Mount
600W 24VDC15A Power Backup Inverter 230VAC/50HZ Single Phase Wall Mount
600W 24VDC15A Power Backup Inverter 230VAC/50HZ Single Phase Wall Mount
600W 24VDC15A Power Backup Inverter 230VAC/50HZ Single Phase Wall Mount
600W 24VDC15A Power Backup Inverter 230VAC/50HZ Single Phase Wall Mount
Specifications
Brand Name :
TBB
Model Number :
CS0615M
Certification :
CE
Place of Origin :
China
MOQ :
1piece
Price :
Negotiable
Payment Terms :
T/T
Delivery Time :
3-7 working days, depending
Packaging Details :
Carton box, Honeycomb plate, Plywood crate
Model :
CS0615L
Power :
600w
Output frequency :
50HZ
DC input :
12VDC
AC output :
230VAC
Output Type :
Single Phase
Application :
Power Backup system
Instalation :
Wallmount/on floor
Display :
LED+LCD
Description

Power Backup Inverter 600W 12VDC25A 230VAC/50HZ Bi-directional Inverter

Energier Essential bi-directional inverter can be used in multiple applications.You can use it
to compose power backup system. Or, with a quick setting,you can compose a simple solar
hybrid system either with grid or diesel-generators.

Comprehensive Protection - Overload protection

Both of charger and output are being protected against overload by both circuit breaker and software. Circuit breaker, in case of overload, the button of which will pop out, you can push back the button to resume operation.

On software, in case of the inverter is too long or too heavily overloaded, it will switch off. . In this case, you need to manually switch on inverter.


Features,

-Bi directional inverter with pure sine wave output
-Can be applied for power backup and solar hybrid system
-Optional CM was available for automatic generator start
-Optional SNMP card for remote internet access
-High performance designed for all kinds of home appliances
-Designed for tropical region with working temperature up to 60℃
-automatic temperature compensation
-Compatible with majority of cheap generators in the market
-Designed to work with weak grid
-Equalization charging program was available
-TBB premium II multi stage charging algorithm with built in

Installations
Basically, Energier essential bi-directional inverter could be installed either vertically on wall or horizontally on floor.
Step 1-4.
600W 24VDC15A Power Backup Inverter 230VAC/50HZ Single Phase Wall Mount600W 24VDC15A Power Backup Inverter 230VAC/50HZ Single Phase Wall Mount600W 24VDC15A Power Backup Inverter 230VAC/50HZ Single Phase Wall Mount600W 24VDC15A Power Backup Inverter 230VAC/50HZ Single Phase Wall Mount
600W 24VDC15A Power Backup Inverter 230VAC/50HZ Single Phase Wall Mount
Specification

Model No. 12Vdc CS0625L CS1040L CS2080L
24Vdc CS0615M CS1020M CS2040M CS3060M CS4080M
48Vdc CS3030S CS4040S
INVERTER
Nominal Voltage 12Vdc, 24Vdc, 48Vdc
power 30mins @25℃ (W) 600 1000 2000 3000 4000
Cont.power@25℃ (W) 600 1000 1800 2500 3600
Cont.power@40℃ (W) 600 1000 1500 2000 3000
Cos φ 0.9-1
Surge 300%
Output voltage【1】 230VAC or 110VAC ± 2% 230VAC ± 2%
Output frequency 50Hz or 60Hz ± 0.1%
Efficiency (MAX.) 12Vdc 88%
24Vdc 88%
48Vdc 92%

Bypass
range

 UPS mode 184VAC-264VAC/92VAC-132VAC 184VAC-264VAC
GEN mode 160VAC-280VAC/80VAC-140VAC 160VAC-280VAC
Crest factor 3:1
THD <3%
Zero load power 17 22 27 36 62
Zero load power (power save mode) 4 5 7 9 15
Output circuit breaker 5A 10A 15A 30A 30A
Overheat protection auto disconnect
Overload protection auto disconnect
shortcut protection auto disconnect
Charger
Nominal Output Voltage 12Vdc, 24Vdc, 48Vdc
Max Output current (A) - adjustable 25/15 40/20 80/40 60/30 80/40
AC Input range UPS mode 184VAC - 264VAC/92VAC-132VAC 184VAC - 264VAC
GEN mode 160VAC - 280VAC/80VAC-140VAC 160VAC - 280VAC
Battery types AGM / GEL / LFP / Flooded
Absorption time variable
Temperature compensation -4mV/℃/cell
Charger circuit breaker 5A 10A 15A 30A 30A
Other Data
Transfer time UPS mode 15ms
GEN mode 2s
Transfer switch 40A
Battery connector M8 x 2
AC connector Terminal block (M3 screw)
Mechanical Data
Enclosure Steel with powder paint
Dimension (mm) 444x186x135 512x216x176
Net Weight (kgs) 9.5 14 16 18.5 22.5
Cooling Forced fan
Protection IP20
Standard
Safety EN60950-1
EMC EN55022,EN55024
【1】Output voltage: 220VAC/60Hz for Philippines
